(888) 312-8812 Login SignupRAYBESTOS 981165FZN Raybestos Element3 Coated Brake Rotor
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
RAYBESTOS 981165FZN Part Description
Manufacturer
Product Description
Raybestos Element3 Coated Brake Rotor
Application Summary
2012-2010 Mercedes-Benz E350 Rear, 2014-2012 Mercedes-Benz C250 Rear, 2013 Mercedes-Benz C300 Rear, 2013-2008 Mercedes-Benz C350 Rear, 2013-2010 Mercedes-Benz E550 Rear
Features & Benefits
- Grey Fusion 4.0(R) Coating
- Grey Fusion 4.0® Coating
- Grey Fusion 4.0(R) coating provides optimal corrosion resistance and faster brake jobs.
- Grey Fusion 4.0® coating provides optimal corrosion resistance and faster brake jobs.
- RPT(R) Rust Prevention Technology
- RPT® Rust Prevention Technology
- RPT(R) Rust Prevention Technology for long lasting rust prevention.
- RPT® Rust Prevention Technology for long lasting rust prevention.
- Cooling Vanes
- Cooling vanes are coated to ensure vanes remain clear of rust and corrosion for optimal airflow and cooling.
- OE Matched
- OE Matched precision and performance.
- Non-Directional Finish
- A non-directional ground finish provides a product that is ready to install right out of the box.
RAYBESTOS 981165FZN Specifications
Product Attributes
| ABS Tone Ring Included | Yes |
| Center Hole Diameter | 2.638 IN |
| Center Hole Diameter | 67 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 0.764 IN |
| Discard Thickness | 19.4 MM |
| Harmonize Code | 8708.30.5030 |
| Inside Diameter | 8.15 IN |
| Inside Diameter | 207 MM |
| Mounting Bolt Hole Circle Diameter | 4.409 IN |
| Mounting Bolt Hole Circle Diameter | 112 MM |
| Mounting Bolt Hole Diameter | 0.606 IN |
| Mounting Bolt Hole Diameter | 15.4 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.862 IN |
| Nominal Thickness | 21.9 MM |
| Outside Diameter | 11.811 IN |
| Outside Diameter | 300 MM |
| Overall Height | 2.26 IN |
| Overall Height | 57.4 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| Surface Type | Smooth |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708305030 |
| Canadian Harmonizing Tariff Code | 8708309990 |
| UPC | 00887213197310 |
RAYBESTOS 981165FZN Cross References
| Brand | Part Number |
|---|---|
| ADVANCE AUTO PARTS | N1000417361ZIC |
| AUTOZONE | 45482, 45482DG, 45482DL |
| Advance Auto Parts | YH200846P |
| BOSCH | 36010984 |
| BRAKEBEST | 36010984, 920722RGS, 980729RGS, 981165, 981165FZN, 981165R |
| Brembo | 09.A760.11, 09.A760.1X |
| CENTRIC | 125.35112CRY, 320.35112 |
| Centric Parts | 125.35112CRY, 121.35115, 125.35115 |
| Dura Corp | BR901060 |
| DuraGo | BR901060 |
| MERCEDES-BENZ | 2044230712, A2044230712, 423121207 |
| Mercedes-Benz | 0004231212 |
| N/A | 120.35112, 121.35112, 125.35112, 126.35112CSL, 126.35112CSR, 126.35112SL, 126.35112SR, 127.35112L, 127.35112R, 128.35112CL, 128.35112CR, 128.35112L, 128.35112R, 320.35112 |
| NAPA BRAKES | SDK6557 |
| PAGID | 355118942 |
| PAGID Racing | 355118942 |
| POWERSTOP | EBR1048EVC |
| Qualis | 45482 |
| UAP | R35112 |
| WAGNER BRAKE | BD180152 |
| WORLDPAC | 1407-76056, 1427-530153 |
| Wagner Brake | BD180739E |
| Winhere | 6620722 |
RAYBESTOS 981165FZN Fits Vehicles
- Mercedes-Benz E400 (2014-2017)
- Mercedes-Benz C300 (2013-2014)
- Mercedes-Benz C250 (2012-2015)
- Mercedes-Benz E350 (2010-2014)
- Mercedes-Benz E550 (2010-2017)
- Mercedes-Benz C350 (2008-2015)
RAYBESTOS 981165FZN Customer Reviews
No reviews yet
Be the first to review this product!
RAYBESTOS 981165FZN Questions & Answers
No questions yet
Be the first to ask a question about this product!
