(888) 312-8812 Login SignupRAYBESTOS 981055FZN Raybestos Element3 Coated Brake Rotor
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
RAYBESTOS 981055FZN Part Description
Manufacturer
Product Description
Raybestos Element3 Coated Brake Rotor
Application Summary
2021-2013 Nissan Pathfinder Front, 2023-2015 Nissan Murano Front, 2021-2014 INFINITI QX60 Front, 2013 INFINITI JX35 Front, 2023 Nissan Z Front
Features & Benefits
- Grey Fusion 4.0(R) Coating
- Grey Fusion 4.0® Coating
- Grey Fusion 4.0(R) coating provides optimal corrosion resistance and faster brake jobs.
- Grey Fusion 4.0® coating provides optimal corrosion resistance and faster brake jobs.
- RPT(R) Rust Prevention Technology
- RPT® Rust Prevention Technology
- RPT(R) Rust Prevention Technology for long lasting rust prevention.
- RPT® Rust Prevention Technology for long lasting rust prevention.
- Cooling Vanes
- Cooling vanes are coated to ensure vanes remain clear of rust and corrosion for optimal airflow and cooling.
- OE Matched
- OE Matched precision and performance.
- Non-Directional Finish
- A non-directional ground finish provides a product that is ready to install right out of the box.
RAYBESTOS 981055FZN Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.68 IN |
| Center Hole Diameter | 68.05 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Discard Thickness | 1.024 IN |
| Discard Thickness | 26 MM |
| Harmonize Code | 8708.30.5030 |
| Inside Diameter | 8.11 IN |
| Inside Diameter | 206 MM |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 4.5 IN |
| Mounting Bolt Hole Circle Diameter | 114.3 MM |
| Mounting Bolt Hole Diameter | 0.504 IN |
| Mounting Bolt Hole Diameter | 12.8 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 1.102 IN |
| Nominal Thickness | 28 MM |
| Outside Diameter | 12.598 IN |
| Outside Diameter | 320 MM |
| Overall Height | 1.94 IN |
| Overall Height | 49.3 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| Surface Type | Smooth |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00887213197303 |
RAYBESTOS 981055FZN Cross References
| Brand | Part Number |
|---|---|
| ADVANCE AUTO PARTS | YH477843, YH477843C |
| ADVICS | B6F067U |
| AUTOPARTSOURCE | 476064 |
| AUTOXTRA | AX901204 |
| AUTOZONE | 76018, 76018DG |
| Advance Auto Parts | YH477843P |
| Autoxtra | AX901204P |
| BECK/ARNLEY | 083-3566 |
| BENDIX | PRT6232 |
| BRAKEBEST | 921552RGS, 981055, 981055FZN, 981055R |
| CENTRIC | 120.42120, 120.42120CRY, 121.42120, 125.42120, 126.42120CSL, 126.42120CSR, 126.42120SL, 126.42120SR, 127.42120L, 127.42120R, 128.42120L, 128.42120R, 320.42120, 120.4212 |
| Centric Parts | 120.42120, 120.42120CRY, 121.42120, 125.42120, 126.42120CSL, 126.42120CSR, 126.42120SL, 126.42120SR, 127.42120L, 127.42120R, 128.42120L, 128.42120R, 320.42120 |
| DATSUN/NISSAN | 402063JA0A, 402063JA0C |
| DURA CORP | BR901204 |
| DuraGo | BR901204, BR90120402, BR901204-02 |
| Dynamic Friction Company | 600-67105 |
| Eurorotor | NI-4043 |
| Nissan | 402063JA0A, 402063JA0C |
| POWERSTOP | JBR1559EVC |
| PROMAX | 14-610000 |
| Qualis | 44765 |
| TopNotch | TN981055GEO |
| UAP | R42120 |
| Ultra Brake | NI-4043 |
| WAGNER BRAKE | BD180592, BD180592E |
| WORLDPAC | 1407-477843, 1427-595536 |
| Winhere | 6621552 |
RAYBESTOS 981055FZN Fits Vehicles
- Nissan 370Z (2020)
- INFINITI QX50 (2016-2017)
- INFINITI Q60 (2017-2022)
- INFINITI Q50 (2014-2023)
- Nissan Z (2023)
- Nissan Murano (2015-2024)
- INFINITI QX60 (2014-2021)
- Nissan Pathfinder (2013-2021)
- INFINITI JX35 (2013)
