RAYBESTOS 980426R Part Description
Manufacturer
Product Description
Raybestos R-Line Brake Rotor
Application Summary
2012-2007 Mercedes-Benz GL450 Front, 2012-2008 Mercedes-Benz GL550 Front, 2012-2010,2006 Mercedes-Benz R350 Front, 2012-2010 Mercedes-Benz GL350 Front, 2011-2008 Mercedes-Benz ML550 Front, 2009-2007 Mercedes-Benz GL320 Front
Features & Benefits
- OE Fit, Form, and Function
- Developed from OE samples and made with G3000-qualified material, ensuring OE fit, form and function for dependable braking.
- SAE Standard
- R-Line Rotors meet the SAE standard for tensile strength, providing structural integrity and a maximum service life.
- Low Initial Lateral Runout and Thickness Variation
- R-Line Rotors have a small parameter lateral runout and a thickness variation ensuring less pedal pulsation, less brake noise, and an extended pad life.
- Mill Balanced Edges
- R-Line Rotors are mill balanced and 100 percent validated. This helps minimize the thickness variation on the rotor and leads to minimized vibration and smoother stopping.
RAYBESTOS 980426R Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.638 IN |
| Center Hole Diameter | 67 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 1.157 IN |
| Discard Thickness | 29.4 MM |
| Harmonize Code | 8708.30.5030 |
| Mounting Bolt Hole Circle Diameter | 4.409 IN |
| Mounting Bolt Hole Circle Diameter | 112 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 1.26 IN |
| Nominal Thickness | 32 MM |
| Outside Diameter | 13.78 IN |
| Outside Diameter | 350 MM |
| Overall Height | 2.146 IN |
| Overall Height | 54.5 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00887213202403 |
RAYBESTOS 980426R Cross References
RAYBESTOS 980426R Fits Vehicles
- Mercedes-Benz R500 (2006-2007)
- Mercedes-Benz R320 (2007-2009)
- Mercedes-Benz ML500 (2006-2007)
- Mercedes-Benz ML450 (2010-2011)
- Mercedes-Benz ML350 (2008-2011)
- Mercedes-Benz G55 AMG (2005-2011)
- Mercedes-Benz GL350 (2010-2012)
- Mercedes-Benz GL550 (2008-2012)
- Mercedes-Benz ML550 (2008-2011)
- Mercedes-Benz GL320 (2007-2009)
- Mercedes-Benz ML320 (2007-2009)
- Mercedes-Benz GL450 (2007-2012)
- Mercedes-Benz R350 (2006-2012)
