DELPHI TC352 Part Description
Manufacturer
Product Description
Control Arm and Ball Joint Assembly
Features & Benefits
- Delphi control arms undergo 100% crack detection and ultrasonic flaw detection to ensure materials match OE specifications
- Delphi machines the ball studs to micron tolerances to guarantee durability and smooth joint operation
- Control arms utilize robot welding for consistent performance and quality
- Anti Corrosion protection applied to each part for optimum corrosion prevention and enhanced aesthetics
DELPHI TC352 Specifications
Product Attributes
| Item Grade | Standard Replacement |
| Position(s) | Front Right Lower |
| Pre-Greased | Yes |
| Grease Fitting Included | No |
| Bushings Included | Yes |
| Ball Joint Stud Type | Grooved |
| Control Arm Construction | Casting/Forged |
| Control Arm Material | Steel |
| Mounting Hardware Included | No |
| Mounting Hole Quantity | 1 |
| Adjustable | No |
| Greaseable | No |
| Control Arm Maximum Width | 2.362 IN |
| Control Arm Maximum Width | 60.00 MM |
| Control Arm Color | Black |
| Ball Joint Thread Diameter | 19.0 MM |
| Ball Joint Stud Length | 53.00 MM |
| Control Arm Maximum Length | 17.323 IN |
| Control Arm Maximum Length | 440.00 MM |
| Mounting Hole Diameter | 12.00 MM |
| Bushing Material | Rubber |
| Bushing Color | Black |
| Finish | Painted |
| Dust Boot Included | Yes |
| Ball Joint Included | Yes |
| Grade Type | Premium |
| Boot Material | Chloroprene Rubber (CR) |
| Boot Color | Black |
| Steering Type | Power |
| Bearing Material | Plastic |
| Dust Boot Material | Chloroprene Rubber (CR) |
| Ball Joint Stud Length | 2.087 IN |
| Mounting Hole Diameter | 0.472 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708807000 |
| Country of Origin (Primary) | TR |
| Harmonized Tariff Code (HTS) | 8708806590 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| UPC | 00689604259276 |
| VMRS Code | 016001001 |
| UNSPSC | 25172013 |
DELPHI TC352 Cross References
| Brand | Part Number |
|---|---|
| Audi | 441 407 152 A, 441 407 152C, 441 407 156 |
| Beck/Arnley | 101-4298 |
| CORTECO | 49395481 |
| DORMAN | 520-710, CB12004, 524-360, CB12004PR |
| Deeza | AD-H201 |
| MAS Industries | CB12004 |
| MEYLE | 1160500026 |
| MOOG Chassis Products | CK90698, K90698, RK90698 |
| Mcquay-Norris | FA1330 |
| Mevotech | CMK90698, MK90698 |
| N/A | CMS9718, GS9718 |
| TRW | JTC255 |
| VAICO | V10-4275 |
DELPHI TC352 Fits Vehicles
- Audi 200 (1989-1991)
- Audi V8 Quattro (1990-1994)
- Audi 200 Quattro (1989-1991)
- Audi 100 (1989-1991)
- Audi 100 Quattro (1989-1991)
