(888) 312-8812 Login SignupDELPHI TC2821 Control Arm and Ball Joint Assembly
Tap to view 2 more
$18199
Limited availability at this price!
1 Day Lead Time
Get it by Monday, Mar 2
DELPHI TC2821 Part Description
Manufacturer
Product Description
Control Arm and Ball Joint Assembly
Features & Benefits
- Delphi control arms undergo 100% crack detection and ultrasonic flaw detection to ensure materials match OE specifications
- Delphi machines the ball studs to micron tolerances to guarantee durability and smooth joint operation
- Control arms utilize robot welding for consistent performance and quality
- Anti Corrosion protection applied to each part for optimum corrosion prevention and enhanced aesthetics
DELPHI TC2821 Specifications
Product Attributes
| Item Grade | Standard Replacement |
| Position(s) | Front Left Lower Forward, Front Left Upper Forward. For the position specific to your vehicle, refer to the Applications. |
| Pre-Greased | Yes |
| Grease Fitting Included | No |
| Bushings Included | Yes |
| Ball Joint Stud Type | Threaded |
| Control Arm Construction | Casting/Forged |
| Control Arm Material | Aluminum |
| Mounting Hardware Included | Yes |
| Mounting Hole Quantity | 1 |
| Greaseable | No |
| Control Arm Maximum Width | 6.693 IN |
| Control Arm Maximum Width | 170.00 MM |
| Control Arm Color | Gray |
| Ball Joint Thread Diameter | 16.00 MM |
| Ball Joint Stud Length | 85.00 MM |
| Control Arm Maximum Length | 18.504 IN |
| Control Arm Maximum Length | 470.00 MM |
| Mounting Hole Diameter | 14.30 MM |
| Bushing Material | Rubber |
| Thread Direction | Clockwise (Right) |
| Bushing Color | Black |
| Finish | Uncoated |
| Dust Boot Included | Yes |
| Ball Joint Included | Yes |
| Grade Type | Premium |
| Boot Material | Chloroprene Rubber (CR) |
| Locking Nut Included | Yes |
| Thread Diameter | 16.00 MM |
| Boot Color | Black |
| Steering Type | Power |
| Bearing Material | Plastic |
| Dust Boot Material | Chloroprene Rubber (CR) |
| Ball Joint Thread Diameter | 0.630 IN |
| Ball Joint Stud Length | 3.346 IN |
| Thread Diameter | 0.630 IN |
| Mounting Hole Diameter | 0.563 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708806590 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Harmonized Tariff Code (Schedule B) | 8708807000 |
| Country of Origin (Primary) | TR |
| UPC | 00689604258705 |
| VMRS Code | 016001001 |
| UNSPSC | 25172013 |
DELPHI TC2821 Cross References
DELPHI TC2821 Fits Vehicles
- BMW 535d (2014-2016)
- BMW ActiveHybrid 5 (2012-2016)
- BMW 650i Gran Coupe (2013-2019)
- BMW 640i Gran Coupe (2013-2019)
- BMW 640i (2012-2018)
- BMW 650i (2012-2018)
- BMW 528i (2011-2016)
- BMW 550i (2011-2016)
- BMW 535i (2011-2016)
