(888) 312-8812 Login SignupDELPHI TC1141 Control Arm and Ball Joint Assembly
Tap to view 20 more
$10249
Limited availability at this price!
5 Day Lead Time
Get it by Tuesday, Mar 10
DELPHI TC1141 Part Description
Manufacturer
Product Description
Control Arm and Ball Joint Assembly
Features & Benefits
- Delphi control arms undergo 100% crack detection and ultrasonic flaw detection to ensure materials match OE specifications
- Delphi machines the ball studs to micron tolerances to guarantee durability and smooth joint operation
- Control arms utilize robot welding for consistent performance and quality
- Anti Corrosion protection applied to each part for optimum corrosion prevention and enhanced aesthetics
DELPHI TC1141 Specifications
Product Attributes
| Item Grade | Standard Replacement |
| Position(s) | Front Left Lower |
| Pre-Greased | Yes |
| Grease Fitting Included | No |
| Bushings Included | Yes |
| Ball Joint Mounting Type | Bolt In |
| Ball Joint Stud Type | Grooved |
| Control Arm Construction | Stamped |
| Control Arm Material | Steel |
| Mounting Hardware Included | No |
| Mounting Hole Quantity | 2 |
| Adjustable | No |
| Greaseable | No |
| Control Arm Maximum Width | 14.409 IN |
| Control Arm Maximum Width | 366.00 MM |
| Control Arm Color | Black |
| Ball Joint Stud Length | 3.110 IN |
| Ball Joint Stud Length | 79.00 MM |
| Control Arm Maximum Length | 15.472 IN |
| Control Arm Maximum Length | 393.00 MM |
| Mounting Hole Diameter | 0.402 IN |
| Mounting Hole Diameter | 10.20 MM |
| Bushing Material | Rubber |
| Bushing Color | Black |
| Finish | Painted |
| Dust Boot Included | Yes |
| Ball Joint Included | Yes |
| Grade Type | Premium |
| Boot Material | Chloroprene Rubber (CR) |
| Boot Color | Black |
| Steering Type | Power |
| Bearing Material | Plastic |
| Dust Boot Material | Chloroprene Rubber (CR) |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708807000 |
| Country of Origin (Primary) | TR |
| Harmonized Tariff Code (HTS) | 8708806590 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| UPC | 00689604250976 |
| VMRS Code | 016001001 |
| UNSPSC | 25172013 |
DELPHI TC1141 Cross References
DELPHI TC1141 Fits Vehicles
- Audi 90 (1990-1991, 1993-1995)
- Audi 90 Quattro (1988-1995)
- Audi Coupe Quattro (1990-1991)
- Audi Cabriolet (1994-1998)
- Audi 80 Quattro (1988-1992)
- Audi 80 (1990-1992)
