(888) 312-8812 Login SignupDELPHI TC1091 Control Arm and Ball Joint Assembly
Tap to view 2 more
$12899
Limited availability at this price!
5 Day Lead Time
Get it by Monday, Mar 9
DELPHI TC1091 Part Description
Manufacturer
Product Description
Control Arm and Ball Joint Assembly
Features & Benefits
- Delphi control arms undergo 100% crack detection and ultrasonic flaw detection to ensure materials match OE specifications
- Delphi machines the ball studs to micron tolerances to guarantee durability and smooth joint operation
- Control arms utilize robot welding for consistent performance and quality
- Anti Corrosion protection applied to each part for optimum corrosion prevention and enhanced aesthetics
DELPHI TC1091 Specifications
Product Attributes
| Item Grade | Standard Replacement |
| Position(s) | Front Right Lower |
| Pre-Greased | Yes |
| Grease Fitting Included | No |
| Bushings Included | Yes |
| Ball Joint Mounting Type | Press In |
| Ball Joint Stud Type | Threaded |
| Control Arm Construction | Stamped |
| Control Arm Material | Steel |
| Mounting Hardware Included | Yes |
| Mounting Hole Quantity | 1 |
| Greaseable | No |
| Control Arm Maximum Width | 3.110 IN |
| Control Arm Maximum Width | 79.00 MM |
| Control Arm Color | Black |
| Ball Joint Thread Diameter | 0.472 IN |
| Ball Joint Thread Diameter | 12.00 MM |
| Ball Joint Stud Length | 0.866 IN |
| Ball Joint Stud Length | 22.00 MM |
| Control Arm Maximum Length | 18.976 IN |
| Control Arm Maximum Length | 482.00 MM |
| Bushing Material | Rubber |
| Thread Direction | Clockwise (Right) |
| Bushing Color | Black |
| Finish | Painted |
| Dust Boot Included | Yes |
| Ball Joint Included | Yes |
| Grade Type | Premium |
| Boot Material | Chloroprene Rubber (CR) |
| Locking Nut Included | Yes |
| Thread Diameter | 12.00 MM |
| Boot Color | Black |
| Steering Type | Power |
| Bearing Material | Plastic |
| Dust Boot Material | Chloroprene Rubber (CR) |
| Thread Diameter | 0.472 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708806590 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Harmonized Tariff Code (Schedule B) | 8708807000 |
| Country of Origin (Primary) | TR |
| UPC | 00689604250709 |
| VMRS Code | 016001001 |
| UNSPSC | 25172013 |
DELPHI TC1091 Cross References
| Brand | Part Number |
|---|---|
| Beck/Arnley | 102-5062 |
| CORTECO | 49397239 |
| DORMAN | CB45144, 520-970, CB45144PR |
| Dorman | 520-918 |
| MAS Industries | CB45124, CB45144, CB45144PR, 523-622 |
| MEVOTECH | CMS20317 |
| MEYLE | 5160500002, 5160500000 |
| MOOG Chassis Products | CK620593, K620593, K620594, RK620593, RK620594 |
| Mevotech | CMS20480 |
| N/A | 30859605, GS20480, 520-970 |
| TRW | JTC1003 |
| VAICO | V95-0113 |
| Volvo | 30863987, 30863989, 30864209, 30883989, 30887033, 30887470, 30889963 |
DELPHI TC1091 Fits Vehicles
- Volvo V40 (2000)
- Volvo S40 (2000)
