DELPHI TA769 Part Description
Manufacturer
Product Description
Tie Rod End
Features & Benefits
- Delphi includes the necessary accessories for a complete job
- Delphi machines the ball studs to micron tolerances to guarantee durability and smooth joint operation
- Delphi tie rods are fatigue tested to avoid failure
- Anti Corrosion protection applied to each part for optimum corrosion prevention and enhanced aesthetics
DELPHI TA769 Specifications
Product Attributes
| Position(s) | Outer |
| Item Grade | Standard Replacement |
| Color | Black |
| End 2 Gender | Female |
| Pre-Greased | Yes |
| Grease Fitting Included | No |
| Dust Boot Included | Yes |
| Width | 37 MM |
| Type | Straight |
| Mounting Hardware Included | Yes |
| End 2 Thread Diameter | 0.551 IN |
| End 2 Thread Diameter | 14.00 MM |
| Height | 71.40 MM |
| Housing Material | Steel |
| Tube Diameter | 0.787 IN |
| Tube Diameter | 20.00 MM |
| Adjustable | No |
| Greaseable | No |
| Weight | 0.79 lb |
| Cone Outside Diameter | 14.40 MM |
| Bearing Material | Plastic |
| End 1 Thread Direction | Clockwise (Right) |
| End 2 Thread Direction | Clockwise (Right) |
| Stud Type | Threaded |
| End 2 Thread Pitch | 2 MM |
| Length - Stud Center to End | 2.913 IN |
| Length - Stud Center to End | 74.00 MM |
| Dust Boot Material | Rubber |
| Tie Rod Material | Steel |
| End 1 Thread Diameter | 0.472 IN |
| End 1 Thread Diameter | 12.00 MM |
| Shank Length | 14.40 MM |
| Stud Length | 14.40 MM |
| Grade Type | Standard Replacement |
| Grade | Premium |
| Shank Length | 0.567 IN |
| Stud Length | 0.567 IN |
| Cone Outside Diameter | 0.567 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708998175 |
| Harmonized Tariff Code (HTS) | 8708998180 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Country of Origin (Primary) | TR |
| UPC | 00689604250051 |
| VMRS Code | 015004045 |
| UNSPSC | 25174205 |
DELPHI TA769 Cross References
| Brand | Part Number |
|---|---|
| Beck/Arnley | 101-1659 |
| CORTECO | 49401521 |
| DORMAN | T2161, T2161PR, 534-329 |
| Import Direct | ER02025 |
| MAS Industries | T2161 |
| MEYLE | 5160203283 |
| MOOG Chassis Products | ES2161R |
| Mcquay-Norris | ES2161R |
| Mevotech | MES2161R, MES3326 |
| N/A | 1330320, 12056586, GES2161R, 612.39017 |
| TRW | JTE426 |
| VAICO | V95-9520 |
| Volvo | 1205658, 1329675, 3516944, 3516944-0 |
DELPHI TA769 Fits Vehicles
- Volvo V90 (1997-1998)
- Volvo S90 (1997-1998)
- Volvo 960 (1992-1997)
- Volvo 940 (1991-1995)
- Volvo 780 (1987-1991)
- Volvo 760 (1983-1990)
- Volvo 740 (1985-1992)
- Volvo 265 (1976-1981)
- Volvo 264 (1976-1982)
- Volvo 262 (1976, 1978-1981)
- Volvo 245 (1975-1989)
- Volvo 244 (1975-1989)
- Volvo 242 (1975-1984)
- Volvo 240 (1990-1993)
