(888) 312-8812 Login SignupRAYBESTOS 980654R Raybestos R-Line Brake Rotor
$12299
Limited availability at this price!
In Stock
Get it by Thursday, Mar 5
RAYBESTOS 980654R Part Description
Manufacturer
Product Description
Raybestos R-Line Brake Rotor
Application Summary
2016-2007 BMW 328i Front, 2016-2009 BMW 328i xDrive Front, 2015-2013 BMW X1 Front, 2018-2013 BMW 320i Front, 2018-2013 BMW 320i xDrive Front, 2019-2017 BMW 330i xDrive Front, 2016-2014 BMW 428i Front, 2018-2017 BMW 330i Front
Features & Benefits
- OE Fit, Form, and Function
- Developed from OE samples and made with G3000-qualified material, ensuring OE fit, form and function for dependable braking.
- SAE Standard
- R-Line Rotors meet the SAE standard for tensile strength, providing structural integrity and a maximum service life.
- Low Initial Lateral Runout and Thickness Variation
- R-Line Rotors have a small parameter lateral runout and a thickness variation ensuring less pedal pulsation, less brake noise, and an extended pad life.
- Mill Balanced Edges
- R-Line Rotors are mill balanced and 100 percent validated. This helps minimize the thickness variation on the rotor and leads to minimized vibration and smoother stopping.
RAYBESTOS 980654R Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 3.11 IN |
| Center Hole Diameter | 79 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 0.88 IN |
| Discard Thickness | 22.35 MM |
| Harmonize Code | 8708.30.5030 |
| Mounting Bolt Hole Circle Diameter | 4.72 IN |
| Mounting Bolt Hole Circle Diameter | 119.9 MM |
| Nominal Thickness | 0.94 IN |
| Nominal Thickness | 23.9 MM |
| Outside Diameter | 12.283 IN |
| Outside Diameter | 312 MM |
| Overall Height | 2.898 IN |
| Overall Height | 73.6 MM |
| Salability Restrictions | No |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00887213202618 |
RAYBESTOS 980654R Cross References
RAYBESTOS 980654R Fits Vehicles
- BMW 325i (2011)
- BMW 220i (2014-2015)
- BMW 430i xDrive Gran Coupe (2017-2020)
- BMW 430i Gran Coupe (2017-2020)
- BMW 430i xDrive (2017-2020)
- BMW 430i (2017-2020)
- BMW 330i GT xDrive (2017-2019)
- BMW 330i xDrive (2017-2019)
- BMW 330i (2016-2019)
- BMW 230i xDrive (2017-2021)
- BMW 230i (2017-2021)
- BMW 228i xDrive (2015-2016)
- BMW 428i xDrive Gran Coupe (2015-2016)
- BMW 428i Gran Coupe (2015-2016)
- BMW 228i (2014-2016)
- BMW 328d xDrive (2014-2018)
- BMW 328d (2014-2018)
- BMW 328i GT xDrive (2014-2016)
- BMW 428i (2014-2016)
- BMW 428i xDrive (2014-2016)
- BMW 320i xDrive (2013-2018)
- BMW 320i (2012-2018)
- BMW X1 (2010-2015)
- BMW 328i xDrive (2009-2016)
- BMW 323i (2006-2011)
- BMW 328xi (2007-2008)
- BMW 328i (2007-2016)
