(888) 312-8812 Login SignupRAYBESTOS 780346FZN Raybestos Element3 Coated Brake Rotor
$5849
Limited availability at this price!
1 Day Lead Time
Get it by Friday, Mar 13
RAYBESTOS 780346FZN Part Description
Manufacturer
Product Description
Raybestos Element3 Coated Brake Rotor
Application Summary
2006-2002 Freightliner Sprinter 2500 Front, 2006-2003 Dodge Sprinter 2500 Front, 2006-2003 Dodge Sprinter 3500 Front, 2006-2002 Freightliner Sprinter 3500 Front
Features & Benefits
- Grey Fusion 4.0(R) Coating
- Grey Fusion 4.0® Coating
- Grey Fusion 4.0(R) coating provides optimal corrosion resistance and faster brake jobs.
- Grey Fusion 4.0® coating provides optimal corrosion resistance and faster brake jobs.
- RPT(R) Rust Prevention Technology
- RPT® Rust Prevention Technology
- RPT(R) Rust Prevention Technology for long lasting rust prevention.
- RPT® Rust Prevention Technology for long lasting rust prevention.
- Cooling Vanes
- Cooling vanes are coated to ensure vanes remain clear of rust and corrosion for optimal airflow and cooling.
- OE Matched
- OE Matched precision and performance.
- Non-Directional Finish
- A non-directional ground finish provides a product that is ready to install right out of the box.
RAYBESTOS 780346FZN Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 3.346 IN |
| Center Hole Diameter | 85 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 0.748 IN |
| Discard Thickness | 19 MM |
| Harmonize Code | 8708.30.5030 |
| Mounting Bolt Hole Circle Diameter | 5.118 IN |
| Mounting Bolt Hole Circle Diameter | 130 MM |
| Mounting Bolt Hole Diameter | 0.591 IN |
| Mounting Bolt Hole Diameter | 15 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.861 IN |
| Nominal Thickness | 21.85 MM |
| Outside Diameter | 11.21 IN |
| Outside Diameter | 284.75 MM |
| Overall Height | 2.836 IN |
| Overall Height | 72.05 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00887213228304 |
RAYBESTOS 780346FZN Cross References
| Brand | Part Number |
|---|---|
| ADVANCE AUTO PARTS | G12276SD, YH145669, YH145669C, YH145669P |
| AUTOXTRA | AX53028 |
| AUTOZONE | 43088DG, 43088DL, 43088 |
| BENDIX | PRT5669, SDR5669 |
| BOSCH | 16010232 |
| BRAKEBEST | 16010232, 780346, 780346FZN, 780346R, 780346RGS |
| Brembo | 09.A922.14 |
| CENTRIC | 120.35074, 121.35074, 125.35074, 125.35074CRY, 126.35074CSL, 126.35074CSR, 126.35074SL, 126.35074SR, 127.35074L, 127.35074R, 320.35074, 320.35074H |
| CHRYSLER | 5114479AA, 5114479AB |
| Casting Numbers | 211719-C, 326262, 9034210112 |
| Centric Parts | 120.35074, 121.35074, 125.35074, 125.35074CRY, 126.35074CSL, 126.35074CSR, 126.35074SL, 126.35074SR, 127.35074L, 127.35074R, 320.35074, 320.35074H |
| DURA CORP | BR53028 |
| DuraGo | BR53028 |
| MERCEDES-BENZ | 9034210112, A9034210115 |
| NEWTEK AUTOMOTIVE | 53028 |
| Newtek Automotive USA | 53028 |
| Omnicraft | QBRR640 |
| PROMAX | 14-53028 |
| QUALIS | 43088 |
| Qualis | 53028 |
| UAP | 53028 |
| VIPAR - VEHICLE INDUSRTY PARTS & MANUFACTURING | X51690 |
| WABCO | PS126265 |
| WABCO - Archived | PS126265 |
| WAGNER BRAKE | BD126265 |
| WINHERE | 6620632 |
| WORLDPAC | 1407-75753 |
| Wagner Brake | BD126265E |
RAYBESTOS 780346FZN Fits Vehicles
- Freightliner Sprinter 3500 (2002-2006)
- Freightliner Sprinter 2500 (2002-2006)
- Mercedes-Benz Sprinter (2004-2006)
- Dodge Sprinter 3500 (2003-2006)
- Dodge Sprinter 2500 (2003-2006)
