(888) 312-8812 Login SignupRAYBESTOS 6130FZN Raybestos Element3 Coated Brake Rotor
$7649
Limited availability at this price!
In Stock
Get it by Friday, Feb 27
RAYBESTOS 6130FZN Part Description
Manufacturer
Product Description
Raybestos Element3 Coated Brake Rotor
Application Summary
1998,1996-1991 Ford Escort Front, 1998-1990 Mazda Protege Front, 1998-1991 Mercury Tracer Front, 1995-1990 Mazda 323 Front
Features & Benefits
- Grey Fusion 4.0® Coating
- Grey Fusion 4.0(R) Coating
- Grey Fusion 4.0® coating provides optimal corrosion resistance and faster brake jobs.
- Grey Fusion 4.0(R) coating provides optimal corrosion resistance and faster brake jobs.
- RPT® Rust Prevention Technology
- RPT(R) Rust Prevention Technology
- RPT® Rust Prevention Technology for long lasting rust prevention.
- RPT(R) Rust Prevention Technology for long lasting rust prevention.
- Cooling Vanes
- Cooling vanes are coated to ensure vanes remain clear of rust and corrosion for optimal airflow and cooling.
- OE Matched
- OE Matched precision and performance.
- Non-Directional Finish
- A non-directional ground finish provides a product that is ready to install right out of the box.
RAYBESTOS 6130FZN Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.17 IN |
| Center Hole Diameter | 55.1 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Discard Thickness | 0.787 IN |
| Discard Thickness | 20 MM |
| Harmonize Code | 8708.30.5030 |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 3.93 IN |
| Mounting Bolt Hole Circle Diameter | 99.8 MM |
| Mounting Bolt Hole Diameter | 0.509 IN |
| Mounting Bolt Hole Diameter | 12.95 MM |
| Mounting Bolt Hole Quantity | 4 |
| Nominal Thickness | 0.865 IN |
| Nominal Thickness | 21.95 MM |
| Outside Diameter | 9.25 IN |
| Outside Diameter | 234.95 MM |
| Overall Height | 1.77 IN |
| Overall Height | 44.95 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 4 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00887213228045 |
RAYBESTOS 6130FZN Cross References
| Brand | Part Number |
|---|---|
| ADVANCE AUTO PARTS | 141634, YH141634, YH141634C, YH141634P |
| ALTROM IMPORTS | A05475 |
| AUTOPART INTERNATIONAL | 78418 |
| AUTOSPECIALTY | JBR548, JBR548E |
| AUTOXTRA | 61996 |
| AUTOZONE | 5475, 5475B, 5475DG, 5475DL, DL5475 |
| Autoxtra | AX5475 |
| BECK/ARNLEY | 080-2381, 083-2381 |
| BENDIX | 141634 |
| BOSCH | 20010311, RBR5475 |
| BRAKE HEADQUARTERS | BR54405 |
| BRAKE PRO | 4616130 |
| BRAKEBEST | 20010311, 6130, 6130FZN, 6130R, 6130RGS, 81-61996, BD61996 |
| BREMBO | 09.5581.80, 25509 |
| Brembo | 09.5581.34 |
| Bridgestone | 7075469 |
| CALIFORNIA DRUM & ROTOR | 61996 |
| CENTRIC | 120.45039, 121.45039, 125.45039, 126.45039SL, 126.45039SR, 127.45039L, 127.45039R, 128.45039L, 128.45039R, 320.45039, 320.45039F |
| CENTURY | 9462 |
| CONTINENTAL-CONTITECH | CW22165 |
| Casting Numbers | 325255, 4524, 54751 |
| Centric Parts | 120.45039, 121.45039, 125.45039, 126.45039SL, 126.45039SR, 127.45039L, 127.45039R, 128.45039L, 128.45039R, 320.45039, 320.45039F |
| DELPHI | RB72 |
| DURA CORP | BR5475 |
| DuraGo | BR31284, BR5475 |
| EIS BRAKES | D17499 |
| EUROROTOR | MA844 |
| FADE FREE | 61996 |
| FORD | F1CZ1125A, F2CZ1125B, F3CZ1125B |
| GREN | 635902 |
| GUARDIAN | 52-61996 |
| INTERBRAKES | MZ341V |
| MAZDA | BR703325X, BR703325XA, BR703325XD |
| MCI | 6057 |
| MIDAS | BR1677 |
| MIGHTY DISTRIBUTING SYSTEM | 5475 |
| MOTORCRAFT | BRR82 |
| NEWTEK AUTOMOTIVE | 5475 |
| Newtek Automotive USA | 5475 |
| PARTS MASTER | P61996 |
| PROMAX | 14-5475 |
| QUALIS | 5475 |
| QUALITEE INTERNATIONAL | 64-74-430 |
| QUALITY BRAND | 5475 |
| QUINTON HAZELL | BDC4386 |
| Qualis | 31284 |
| ROADMATES | 526150 |
| ROCKHILL | 5475 |
| SEARS | 17882 |
| STANDARD ROTORS AND DRUMS | 5475 |
| THE UNIVERSAL GROUP | 102750 |
| TRUSTAR | 474430, R74430 |
| TRW | DF3089S |
| UAP | 5475 |
| Ultra Brake | MA-844 |
| Universal | 102750 |
| VIPAR - VEHICLE INDUSRTY PARTS & MANUFACTURING | X50564 |
| WAGNER BRAKE | BD61996, SB6130 |
| WINHERE | 442001, YH2001 |
RAYBESTOS 6130FZN Fits Vehicles
- Mazda Protege (1990-2001)
- Mazda 323 (1990-1995)
- Mercury Tracer (1991-1998)
- Ford Escort (1991-1998)
