RAYBESTOS 981000 Raybestos Specialty - Street Performance Brake Rotor

No Stock Available

We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.

We may have similar parts for sale. Search Alternatives >

RAYBESTOS 981000 Part Description

Manufacturer

RAYBESTOS

Product Description

Raybestos Specialty - Street Performance Brake Rotor

Application Summary

2015-2012 Mercedes-Benz ML350 Front, 2018-2016 Mercedes-Benz GLE350 Front, 2015 Mercedes-Benz ML250 Front, 2016 Mercedes-Benz GLE300d Front

Features & Benefits

  • Application Specific Enhanced Iron
  • Raybestos® Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
  • Raybestos(R) Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
  • Cooling Vanes
  • The cooling vanes match OE configurations and provide optimal cooling and reduced fade.
  • Application Specific Coating
  • Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0® coating on the entire rotor
  • Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0(R) coating on the entire rotor
  • Black fusion coating on the rotor hat and Grey Fusion 4.0® coating on the rotor inboard surface and cooling vanes
  • Black fusion coating on the rotor hat and Grey Fusion 4.0(R) coating on the rotor inboard surface and cooling vanes
  • Turned Finish
  • Turned finish minimizes noise and improves responsiveness for smoother stops.
  • S-Groove Slot
  • Depending on the application, some Raybestos® Performance Rotors are designed with a patented S-Groove Slot.
  • Depending on the application, some Raybestos(R) Performance Rotors are designed with a patented S-Groove Slot.

RAYBESTOS 981000 Specifications

Product Attributes

ABS Tone Ring Included No
Center Hole Diameter 2.638 IN
Center Hole Diameter 67 MM
Conventional Or Drum-In-Hat Type Rotor Conventional
Discard Thickness 1.158 IN
Discard Thickness 29.4 MM
Harmonize Code 8708.30.5030
Inside Diameter 8.15 IN
Inside Diameter 207 MM
Mounting Bolt Hole Circle Diameter 4.409 IN
Mounting Bolt Hole Circle Diameter 112 MM
Mounting Bolt Hole Diameter 0.595 IN
Mounting Bolt Hole Diameter 15.1 MM
Mounting Bolt Hole Quantity 5
Nominal Thickness 1.26 IN
Nominal Thickness 32 MM
Outside Diameter 12.992 IN
Outside Diameter 330 MM
Overall Height 2.144 IN
Overall Height 54.45 MM
Salability Restrictions No
Solid Or Vented Type Rotor Vented
Stud/Lug Hole Quantity 5
Surface Type Smooth
UNSPSC Code 25171715

Additional Information

Country of Origin (Primary) CN
Canadian Harmonizing Tariff Code 8708309990
Harmonized Tariff Code (HTS) 8708305030
UPC 00887213170573

RAYBESTOS 981000 Cross References

BrandPart Number
ADVANCE AUTO PARTSYH425720P
ATE BRAKE PRODUCTSSP00003, 432178, 432179, SP32178
AUTOZONE45593, 45593DG, 45593DL, 45594
Advance Auto PartsYH425720
BRAKEBEST36011593, 921432RGS, 981000, 981000FZN, 981000R
Brembo09.A956.11, 09.A956.1X
CENTRIC120.35134, 121.35134, 125.35134, 126.35134SL, 126.35134SR, 127.35134L, 127.35134R, 320.35134, 320.35134C
Centric Parts120.35134, 121.35134, 125.35134, 126.35134SL, 126.35134SR, 127.35134L, 127.35134R, 320.35134C, 320.35134
DURA CORPBR901354
DuraGoBR901354
Dynamic Friction Company600-63144
MAGMA PRODUCTSPSR385106
MERCEDES-BENZ1664210612, 1664211300
NEOTEK1065532GF
NEWTEK AUTOMOTIVER1354
Newtek Automotive USAR1354
POWERSTOPEBR1452EVC, EBR1460EVC
PROMAX14-620006
Qualis45593
TopNotchTN981000GEO
WORLDPAC1407-425720, 1427-540195
Winhere6621432

RAYBESTOS 981000 Fits Vehicles

  • Mercedes-Benz GLE43 AMG (2017-2019)
  • Mercedes-Benz GLE350d (2016)
  • Mercedes-Benz GLE400 (2016)
  • Mercedes-Benz ML400 (2015)
  • Mercedes-Benz GLE350 (2016-2018)
  • Mercedes-Benz GLE300d (2016)
  • Mercedes-Benz ML250 (2015)
  • Mercedes-Benz ML350 (2012-2015)
