RAYBESTOS 981001 Part Description
Manufacturer
Product Description
Raybestos Specialty - Street Performance Coated Brake Rotor
Application Summary
2015-2012 Honda Civic Front, 2013 Acura ILX Front
Features & Benefits
- Application Specific Enhanced Iron
- Raybestos® Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Raybestos(R) Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Cooling Vanes
- The cooling vanes match OE configurations and provide optimal cooling and reduced fade.
- Application Specific Coating
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0® coating on the entire rotor
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0(R) coating on the entire rotor
- Black fusion coating on the rotor hat and Grey Fusion 4.0® coating on the rotor inboard surface and cooling vanes
- Black fusion coating on the rotor hat and Grey Fusion 4.0(R) coating on the rotor inboard surface and cooling vanes
- Turned Finish
- Turned finish minimizes noise and improves responsiveness for smoother stops.
- S-Groove Slot
- Depending on the application, some Raybestos® Performance Rotors are designed with a patented S-Groove Slot.
- Depending on the application, some Raybestos(R) Performance Rotors are designed with a patented S-Groove Slot.
RAYBESTOS 981001 Specifications
Product Attributes
| Center Hole Diameter | 2.524 IN |
| Center Hole Diameter | 64.1 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 0.827 IN |
| Discard Thickness | 21 MM |
| Harmonize Code | 8708.30.5030 |
| Inside Diameter | 6.772 IN |
| Inside Diameter | 172 MM |
| Mounting Bolt Hole Circle Diameter | 4.5 IN |
| Mounting Bolt Hole Circle Diameter | 114.3 MM |
| Mounting Bolt Hole Diameter | 4.5 IN |
| Mounting Bolt Hole Diameter | 114.3 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.906 IN |
| Nominal Thickness | 23 MM |
| Outside Diameter | 11.093 IN |
| Outside Diameter | 281.75 MM |
| Overall Height | 1.858 IN |
| Overall Height | 47.2 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| Surface Type | Smooth |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00887213082623 |
RAYBESTOS 981001 Cross References
| Brand | Part Number |
|---|---|
| AUTOXTRA | AX901186 |
| AUTOZONE | 74014 |
| AutoZone | 74014DL |
| Autoxtra | AX901186P |
| BRAKEBEST | 981001, 981001FZN, 981001R, 981001RGS |
| Brembo | 09.A455.11 |
| Centric Parts | 120.40078, 121.40078 |
| DURA CORP | BR901186 |
| DuraGo | BR901186, BR901186-01 |
| HONDA | 45251S7AE10, 45251SMGG11 |
| NAPA BRAKES | SDK6121 |
| NEWTEK AUTOMOTIVE | R1186 |
| Newtek Automotive USA | R1186 |
| POWERSTOP | JBR1556EVC |
| PROMAX | 14-31622 |
| PowerStop | PSR6620991 |
| UAP | 2901186, R40078 |
| WAGNER | BD180560E |
| WAGNER BRAKE | BD180560 |
| WINHERE | 6620350 |
| WORLDPAC | 1427-731793 |
RAYBESTOS 981001 Fits Vehicles
- Acura ILX (2013)
- Honda Civic (2012-2015)
