(888) 312-8812 Login SignupDELPHI AF10324 Mass Air Flow Sensor
$24249
Limited availability at this price!
1 Day Lead Time
Get it by Wednesday, Mar 11
DELPHI AF10324 Part Description
Manufacturer
Product Description
Mass Air Flow Sensor
Features & Benefits
- Delphi mass air flow sensors are the global benchmark for accuracy and signal noise
- Delphi mass air flow sensors feature high quality sensing elements for outstanding performance over a wide range of ambient temperatures
- Delphi is a manufacturer of OE mass air flow sensors since their first use over 30 years ago
- All parts are calibrated and tested to match the OE part
- Probe solution offered wherever possible to reduce repair time by eliminating the need to replace the flow tube
- Delphi OE technology validated to match the vehicle applications
DELPHI AF10324 Specifications
Product Attributes
| Package Contents | Mass Air Flow Sensor - Complete Assembly |
| Item Grade | Premium |
| Color | Black |
| Housing Included | Yes |
| Inlet Connection Diameter | 3.23 IN |
| Inlet Connection Diameter | 82 MM |
| Outlet Connection Diameter | 3.3 IN |
| Outlet Connection Diameter | 83.1 MM |
| Terminal Type | Blade |
| Mounting Hardware Included | No |
| Universal Or Specific Fit | Specific |
| Grade Type | Standard Replacement |
| Connector Quantity | 1 |
| Connector Shape | Rectangle |
| Mounting Hole Quantity | 4 |
| Housing Material | Plastic |
| Terminal Quantity | 7 |
| Connector Gender | Female |
| Terminal Gender | Male |
| Wiring Harness Included | No |
| Mounting Type | Bolt-On |
| Mounting Bracket Included | No |
| Sensor Casing Length | 128 MM |
| Sensor Casing Width | 132 MM |
| Voltage | 12.0 2H |
| Gasket Or Seal Included | Yes |
| Bolt Hole Center To Bolt Hole Center | 112.00 MM |
| Mounting Hole Diameter | 6.5 MM |
| Seal Outside Diameter | 78 mm |
| Seal Quantity | 1 |
| Sensor Casing Length | 5.0 IN |
| Sensor Casing Width | 5.1 IN |
| Bolt Hole Center To Bolt Hole Center | 4.40 IN |
| Mounting Hole Diameter | 0.2 IN |
| Seal Outside Diameter | 3 IN |
| Intake Air Temperature (IAT) Included | Yes |
Additional Information
| Warranty Distance UOM | DH |
| Warranty Distance | 12000 |
| Harmonized Tariff Code (Schedule B) | 9026800000 |
| Warranty Time UOM | MO |
| Warranty Time | 12 |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 9026802000 |
| UPC | 00689604244647 |
| VMRS Code | 045021019 |
| UNSPSC | 41111931 |
DELPHI AF10324 Cross References
| Brand | Part Number |
|---|---|
| ACDelco | 2133616 |
| Airtex | 5S2783 |
| BWD | 221114M |
| Beck/Arnley | 180-0283 |
| Blue Streak Electronics New | MF21114N |
| CARDONE Reman | 74-60020 |
| Carquest | MQ7272 |
| Dorman | 917-967 |
| Duralast | DL-6143 |
| GLOBAL PARTS DISTRIBUTORS | 1813315 |
| Mitsubishi | MD343605 |
| N/A | 245-1143 |
| NAPA Reman Computers | XTP460020 |
| NGK SPARK PLUGS | MG0080 |
| NTK | MG0080 |
| Richporter | MA307 |
| Spectra Premium | MA307 |
| Standard Motor Products | MF21114 |
| WALKER PRODUCTS | 245-1143 |
| Wells | SU4306 |
DELPHI AF10324 Fits Vehicles
- Mitsubishi Lancer (2002-2007)
- Mitsubishi Mirage (1998-2002)
- Mitsubishi Montero Sport (1997-1998)
