RAYBESTOS 980865FZN Part Description
Manufacturer
Product Description
Raybestos Element3 Coated Brake Rotor
Application Summary
2021-2013 Nissan NV200 Front, 2023-2018,2014-2011 Nissan LEAF Front
Features & Benefits
- Grey Fusion 4.0(R) Coating
- Grey Fusion 4.0® Coating
- Grey Fusion 4.0(R) coating provides optimal corrosion resistance and faster brake jobs.
- Grey Fusion 4.0® coating provides optimal corrosion resistance and faster brake jobs.
- RPT(R) Rust Prevention Technology
- RPT® Rust Prevention Technology
- RPT(R) Rust Prevention Technology for long lasting rust prevention.
- RPT® Rust Prevention Technology for long lasting rust prevention.
- Cooling Vanes
- Cooling vanes are coated to ensure vanes remain clear of rust and corrosion for optimal airflow and cooling.
- OE Matched
- OE Matched precision and performance.
- Non-Directional Finish
- A non-directional ground finish provides a product that is ready to install right out of the box.
RAYBESTOS 980865FZN Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.68 IN |
| Center Hole Diameter | 68.05 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Discard Thickness | 1.024 IN |
| Discard Thickness | 26 MM |
| Harmonize Code | 8708.30.5030 |
| Inside Diameter | 7 IN |
| Inside Diameter | 177.8 MM |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 4.5 IN |
| Mounting Bolt Hole Circle Diameter | 114.3 MM |
| Mounting Bolt Hole Diameter | 0.495 IN |
| Mounting Bolt Hole Diameter | 12.55 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 1.102 IN |
| Nominal Thickness | 28 MM |
| Outside Diameter | 11.118 IN |
| Outside Diameter | 282.4 MM |
| Overall Height | 1.72 IN |
| Overall Height | 43.7 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| Surface Type | Smooth |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00887213146806 |
RAYBESTOS 980865FZN Cross References
| Brand | Part Number |
|---|---|
| ADVICS | B6F065U |
| AUTOPARTSOURCE | 476395 |
| AUTOXTRA | AX901202 |
| Advance Auto Parts | G09558SD, YH321922HC, YH321922P |
| AutoZone | 44723, 44723DG |
| Autoxtra | AX901202P |
| BENDIX | PRT6120 |
| BOSCH | 40011475 |
| BRAKEBEST | 40011475, 980865FZN, 980865R |
| Brembo | 09.C544.11 |
| CENTRIC | 120.42112, 120.42112CRY, 121.42112, 320.42112 |
| Centric Parts | 120.42112, 120.42112CRY, 121.42112, 320.42112 |
| DATSUN/NISSAN | 402063LM0A, 402063NA0A |
| DURA CORP | BR901202 |
| DuraGo | BR901202, BR901202-02 |
| Dynamic Friction Company | 600-67103 |
| NEWTEK AUTOMOTIVE | 31570 |
| Newtek Automotive USA | 31570 |
| Nissan | 402063LM0A, 402063NA0A |
| Omnicraft | QBRR530 |
| POWERSTOP | JBR1557EVC |
| QUALIS | 44733 |
| TopNotch | TN980865GEO |
| UAP | R42112 |
| WAGNER BRAKE | BD180432 |
| WORLDPAC | 1407-321922, 1427-731948 |
| Wagner Brake | BD180432E |
| Winhere | 6620785 |
RAYBESTOS 980865FZN Fits Vehicles
- Chevrolet City Express (2015-2018)
- Nissan NV200 (2013-2021)
- Nissan LEAF (2011-2014, 2018-2025)
