(888) 312-8812 Login SignupRAYBESTOS 980488FZN Raybestos Element3 Coated Brake Rotor
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
RAYBESTOS 980488FZN Part Description
Manufacturer
Product Description
Raybestos Element3 Coated Brake Rotor
Application Summary
2015-2010 Lexus IS250 Rear, 2015-2006 Lexus IS350 Rear, 2011-2007 Lexus GS350 Rear, 2006 Lexus GS300 Rear, 2007-2006 Lexus GS430 Rear, 2011-2007 Lexus GS450h Rear, 2011-2008 Lexus GS460 Rear
Features & Benefits
- Grey Fusion 4.0(R) Coating
- Grey Fusion 4.0® Coating
- Grey Fusion 4.0(R) coating provides optimal corrosion resistance and faster brake jobs.
- Grey Fusion 4.0® coating provides optimal corrosion resistance and faster brake jobs.
- RPT(R) Rust Prevention Technology
- RPT® Rust Prevention Technology
- RPT(R) Rust Prevention Technology for long lasting rust prevention.
- RPT® Rust Prevention Technology for long lasting rust prevention.
- Cooling Vanes
- Cooling vanes are coated to ensure vanes remain clear of rust and corrosion for optimal airflow and cooling.
- OE Matched
- OE Matched precision and performance.
- Non-Directional Finish
- A non-directional ground finish provides a product that is ready to install right out of the box.
RAYBESTOS 980488FZN Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.441 IN |
| Center Hole Diameter | 62 MM |
| Conventional Or Drum-In-Hat Type Rotor | Drum-In-Hat |
| Discard Thickness | 0.65 IN |
| Discard Thickness | 16.5 MM |
| Harmonize Code | 8708.30.5030 |
| Mounting Bolt Hole Circle Diameter | 4.5 IN |
| Mounting Bolt Hole Circle Diameter | 114.3 MM |
| Mounting Bolt Hole Diameter | 0.573 IN |
| Mounting Bolt Hole Diameter | 14.55 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.709 IN |
| Nominal Thickness | 18 MM |
| Outside Diameter | 12.205 IN |
| Outside Diameter | 310 MM |
| Overall Height | 2.642 IN |
| Overall Height | 67.1 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00887213146967 |
RAYBESTOS 980488FZN Cross References
| Brand | Part Number |
|---|---|
| ADVANCE AUTO PARTS | N1000170800APO, YH200509, YH200509C, YH200509P |
| ADVICS | A6R038U |
| AUTOXTRA | AX900548 |
| AUTOZONE | 31446, 31446DG |
| BENDIX | PRT5940 |
| BOSCH | 50011462 |
| BRAKEBEST | 50011462, 980488, 980488FZN, 980488RGS |
| BrakeBest | 921770RGS |
| CENTRIC | 120.44141, 121.44141, 126.44141CSL, 126.44141CSR, 126.44141SL, 126.44141SR, 127.44141CL, 127.44141CR, 127.44141L, 127.44141R, 128.44141CL, 128.44141CR, 128.44141L, 128.44141R, 320.44141, 320.44141F |
| Centric Parts | 120.44141, 121.44141, 126.44141CSL, 126.44141CSR, 126.44141SL, 126.44141SR, 127.44141CL, 127.44141CR, 127.44141L, 127.44141R, 128.44141CL, 128.44141CR, 128.44141L, 128.44141R, 320.44141, 320.44141F |
| DURA CORP | BR31446, BR900548, BR90054802 |
| DuraGo | 900548, BR900548 |
| NAPA BRAKES | SDK6525 |
| NEWTEK AUTOMOTIVE | 31446 |
| Newtek Automotive USA | 31446 |
| PROMAX | 14-31446 |
| Qualis | 44667 |
| TOYOTA | 4243130290, 4243130330 |
| TRW | 6063 |
| UAP | 31446 |
| WABCO | PS900548 |
| WABCO - Archived | PS900548 |
| WAGNER BRAKE | BD180047 |
| WINHERE | 6620384 |
| WORLDPAC | 1407-80440, 1427-731858 |
RAYBESTOS 980488FZN Fits Vehicles
- Lexus IS250 (2010-2015)
- Lexus GS460 (2008-2011)
- Lexus GS350 (2007-2011)
- Lexus GS450h (2007-2011)
- Lexus IS350 (2006-2015)
- Lexus GS300 (2006)
- Lexus GS430 (2006-2007)
