(888) 312-8812 Login SignupRAYBESTOS 980471FZN Raybestos Element3 Coated Brake Rotor
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
RAYBESTOS 980471FZN Part Description
Manufacturer
Product Description
Raybestos Element3 Coated Brake Rotor
Application Summary
2008-2006 Volkswagen Passat Front, 2012-2009 Volkswagen CC Front, 2013 Volkswagen Golf Front, 2013 Volkswagen GTI Front, 2013-2012 Volkswagen Golf R Front, 2008 Volkswagen R32 Front, 2011 Audi A3 Quattro Front
Features & Benefits
- Grey Fusion 4.0(R) Coating
- Grey Fusion 4.0® Coating
- Grey Fusion 4.0(R) coating provides optimal corrosion resistance and faster brake jobs.
- Grey Fusion 4.0® coating provides optimal corrosion resistance and faster brake jobs.
- RPT(R) Rust Prevention Technology
- RPT® Rust Prevention Technology
- RPT(R) Rust Prevention Technology for long lasting rust prevention.
- RPT® Rust Prevention Technology for long lasting rust prevention.
- Cooling Vanes
- Cooling vanes are coated to ensure vanes remain clear of rust and corrosion for optimal airflow and cooling.
- OE Matched
- OE Matched precision and performance.
- Non-Directional Finish
- A non-directional ground finish provides a product that is ready to install right out of the box.
RAYBESTOS 980471FZN Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.559 IN |
| Center Hole Diameter | 65 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 1.063 IN |
| Discard Thickness | 27 MM |
| Harmonize Code | 8708.30.5030 |
| Mounting Bolt Hole Circle Diameter | 4.409 IN |
| Mounting Bolt Hole Circle Diameter | 112 MM |
| Mounting Bolt Hole Quantity | 9 |
| Nominal Thickness | 1.18 IN |
| Nominal Thickness | 29.95 MM |
| Outside Diameter | 13.58 IN |
| Outside Diameter | 344.95 MM |
| Overall Height | 1.958 IN |
| Overall Height | 49.75 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 9 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00887213146141 |
RAYBESTOS 980471FZN Cross References
RAYBESTOS 980471FZN Fits Vehicles
- Audi A3 (2011)
- Volkswagen Golf R (2012-2013)
- Audi A3 Quattro (2011)
- Volkswagen GTI (2013)
- Volkswagen Golf (2013)
- Volkswagen Passat CC (2009-2011)
- Seat Leon (2006-2012)
- Audi S3 (2008-2012)
- Volkswagen CC (2009-2012)
- Volkswagen R32 (2008)
- Volkswagen Passat (2006-2009)
