RAYBESTOS 980427FZN Raybestos Element3 Coated Brake Rotor

★★★★★ (0) Write a Review
980427FZN by RAYBESTOS - Raybestos Element3 Coated Brake Rotor
RAYBESTOS

No Stock Available

We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.

We may have similar parts for sale. Search Alternatives >

RAYBESTOS 980427FZN Part Description

Manufacturer

RAYBESTOS

Product Description

Raybestos Element3 Coated Brake Rotor

Application Summary

2011-2006 Mercedes-Benz ML350 Front, 2012,2010-2006 Mercedes-Benz R350 Front, 2009-2007 Mercedes-Benz ML320 Front, 2007-2006 Mercedes-Benz ML500 Front, 2007-2006 Mercedes-Benz R500 Front, 2009-2007 Mercedes-Benz R320 Front

Features & Benefits

  • Grey Fusion 4.0(R) Coating
  • Grey Fusion 4.0® Coating
  • Grey Fusion 4.0(R) coating provides optimal corrosion resistance and faster brake jobs.
  • Grey Fusion 4.0® coating provides optimal corrosion resistance and faster brake jobs.
  • RPT(R) Rust Prevention Technology
  • RPT® Rust Prevention Technology
  • RPT(R) Rust Prevention Technology for long lasting rust prevention.
  • RPT® Rust Prevention Technology for long lasting rust prevention.
  • Cooling Vanes
  • Cooling vanes are coated to ensure vanes remain clear of rust and corrosion for optimal airflow and cooling.
  • OE Matched
  • OE Matched precision and performance.
  • Non-Directional Finish
  • A non-directional ground finish provides a product that is ready to install right out of the box.

RAYBESTOS 980427FZN Specifications

Product Attributes

ABS Tone Ring Included No
Center Hole Diameter 2.638 IN
Center Hole Diameter 67 MM
Conventional Or Drum-In-Hat Type Rotor Conventional
Discard Thickness 1.157 IN
Discard Thickness 29.4 MM
Harmonize Code 8708.30.5030
Mounting Bolt Hole Circle Diameter 4.409 IN
Mounting Bolt Hole Circle Diameter 112 MM
Mounting Bolt Hole Quantity 5
Nominal Thickness 1.26 IN
Nominal Thickness 32 MM
Outside Diameter 12.992 IN
Outside Diameter 330 MM
Overall Height 2.146 IN
Overall Height 54.5 MM
Salability Restrictions No
Solid Or Vented Type Rotor Vented
Stud/Lug Hole Quantity 5
UNSPSC Code 25171715

Additional Information

Country of Origin (Primary) CN
Canadian Harmonizing Tariff Code 8708309990
Harmonized Tariff Code (HTS) 8708305030
UPC 00887213146066

RAYBESTOS 980427FZN Cross References

BrandPart Number
ADVANCE AUTO PARTSYH200528, YH200528C, YH200528P
AUTOZONE45413, 45413DG
BENDIXBPR5869, PRT5869
BOSCH36010990
BRAKEBEST36010990, 980427, 980427FZN, 980427R, 980427RGS
Brembo09.R104.11
CENTRIC120.35089, 121.35089, 125.35089, 125.35089CRY, 126.35089CSL, 126.35089CSR, 126.35089SL, 126.35089SR, 127.35089R, 127.35089CL, 127.35089CR, 127.35089L, 128.35089CL, 128.35089CR, 128.35089L, 128.35089R, 320.35089, 320.35089C, 320.35089H
Casting Numbers211786-C
Centric Parts120.35089, 121.35089, 125.35089, 125.35089CRY, 126.35089CSL, 126.35089CSR, 126.35089SL, 126.35089SR, 127.35089CL, 127.35089CR, 127.35089L, 127.35089R, 128.35089CL, 128.35089CR, 128.35089L, 128.35089R, 320.35089, 320.35089C, 320.35089H
DURA CORPBR34298, BR900872
DuraGo900872, BR900872
MERCEDES-BENZ1644210412, 1644211312
NAPA BRAKESSDK6438
NEWTEK AUTOMOTIVE34298
Newtek Automotive USA34298
OmnicraftQBRR563
PAGID355113172
PAGID Racing355113172
PILENGAV187
POWERSTOPEBR676EVC
PROMAX14-34298
Qualis45413
TRW4471
TopNotchTN980427GEO
UAP34298
WABCOPS34298
WABCO - ArchivedPS34298
WAGNER BRAKEBD180037, BD180037E
WINHERE6620397
WORLDPAC1407-83120, 1427-530251

RAYBESTOS 980427FZN Fits Vehicles

  • Mercedes-Benz ML550 (2008-2011)
  • Mercedes-Benz GL550 (2008)
  • Mercedes-Benz GL450 (2007-2008)
  • Mercedes-Benz GL320 (2007-2008)
  • Mercedes-Benz ML450 (2010-2011)
  • Mercedes-Benz ML320 (2007-2009)
  • Mercedes-Benz R320 (2007-2009)
  • Mercedes-Benz R350 (2006-2012)
  • Mercedes-Benz R500 (2006-2007)
  • Mercedes-Benz ML350 (2006-2011)
  • Mercedes-Benz ML500 (2006-2007)
