(888) 312-8812 Login SignupRAYBESTOS 680679FZN Raybestos Element3 Coated Brake Rotor
$10899
Limited availability at this price!
1 Day Lead Time
Get it by Wednesday, Mar 11
RAYBESTOS 680679FZN Part Description
Manufacturer
Product Description
Raybestos Element3 Coated Brake Rotor
Application Summary
2023-2021,2019-2008 Ford E-350 Super Duty Rear, 2014-2008 Ford E-250 Rear, 2014-2008 Ford E-150 Rear, 2012-2011,2009-2006 Ford F-350 Rear
Features & Benefits
- Grey Fusion 4.0(R) Coating
- Grey Fusion 4.0® Coating
- Grey Fusion 4.0(R) coating provides optimal corrosion resistance and faster brake jobs.
- Grey Fusion 4.0® coating provides optimal corrosion resistance and faster brake jobs.
- RPT(R) Rust Prevention Technology
- RPT® Rust Prevention Technology
- RPT(R) Rust Prevention Technology for long lasting rust prevention.
- RPT® Rust Prevention Technology for long lasting rust prevention.
- Cooling Vanes
- Cooling vanes are coated to ensure vanes remain clear of rust and corrosion for optimal airflow and cooling.
- OE Matched
- OE Matched precision and performance.
- Non-Directional Finish
- A non-directional ground finish provides a product that is ready to install right out of the box.
RAYBESTOS 680679FZN Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 5 IN |
| Center Hole Diameter | 127 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Discard Thickness | 1.35 IN |
| Discard Thickness | 34.3 MM |
| Harmonize Code | 8708.30.5030 |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 5 IN |
| Mounting Bolt Hole Circle Diameter | 127 MM |
| Mounting Bolt Hole Diameter | 0.62 IN |
| Mounting Bolt Hole Diameter | 15.75 MM |
| Nominal Thickness | 1.42 IN |
| Nominal Thickness | 36.05 MM |
| Outside Diameter | 13.583 IN |
| Outside Diameter | 345 MM |
| Overall Height | 3.563 IN |
| Overall Height | 90.5 MM |
| Salability Restrictions | No |
| Stud/Lug Hole Quantity | 8 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708305030 |
| Canadian Harmonizing Tariff Code | 8708309990 |
| UPC | 00887213091250 |
RAYBESTOS 680679FZN Cross References
| Brand | Part Number |
|---|---|
| ADVANCE AUTO PARTS | YH246570, YH246570C, YH246570P |
| AUTOXTRA | AX900480 |
| AUTOZONE | 42265, 42265DG, DL42265 |
| Advance Auto Parts | G09157SD |
| Autoxtra | AX900480P |
| BENDIX | PRT5916, SDR5916 |
| BRAKEBEST | 680679, 680679FZN, 680679R, 680679RGS |
| Brembo | 09.E288.11 |
| CENTRIC | 120.65123, 120.65123CRY, 121.65123, 126.65123SL, 126.65123SR, 126.65123CSL, 126.65123CSR, 127.65123L, 127.65123R, 320.65123, 320.65123F, 321.65123 |
| Casting Numbers | 326431 |
| Centric Parts | 120.65123, 120.65123CRY, 121.65123, 126.65123CSL, 126.65123CSR, 126.65123SL, 126.65123SR, 127.65123L, 127.65123R, 320.65123, 320.65123F, 321.65123 |
| DURA CORP | BR54162, BR900480, BR90048002 |
| DuraGo | 900480, BR900480, BR90048002, BR900480-02 |
| FORD | 8C2Z2C026C |
| Ford | NC2Z2C026B |
| MONROE BRAKES | BD126468 |
| NEWTEK AUTOMOTIVE | 54162 |
| Newtek Automotive USA | 54162 |
| POWERSTOP | AR85123EVC |
| PROMAX | 14-54162 |
| Qualis | 42265 |
| TopNotch | TN680679GEO |
| UAP | 2900480, 54162, 680679 |
| WABCO | PS126468 |
| WABCO - Archived | PS126468 |
| WAGNER BRAKE | BD126468, BD126468E |
| WINHERE | 6620901 |
| WORLDPAC | 1407-246570, 1427-731854 |
RAYBESTOS 680679FZN Fits Vehicles
- Ford F-250 (2005, 2009)
- Ford E-350 Econoline (2008)
- Ford E-150 Econoline (2008)
- Ford F-350 (2006-2009, 2011-2012)
- Ford E-350 Super Duty (2008-2019, 2021-2023)
- Ford E-150 (2008-2014)
- Ford E-250 (2008-2014)
