(888) 312-8812 Login SignupRAYBESTOS 580756FZN Raybestos Element3 Coated Brake Rotor
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
RAYBESTOS 580756FZN Part Description
Manufacturer
Product Description
Raybestos Element3 Coated Brake Rotor
Application Summary
2015-2010 Chevrolet Camaro Front, 2013-2012 Buick Regal Front, 2009 Pontiac G8 Front, 2017-2014 Chevrolet SS Front
Features & Benefits
- Grey Fusion 4.0(R) Coating
- Grey Fusion 4.0® Coating
- Grey Fusion 4.0(R) coating provides optimal corrosion resistance and faster brake jobs.
- Grey Fusion 4.0® coating provides optimal corrosion resistance and faster brake jobs.
- RPT(R) Rust Prevention Technology
- RPT® Rust Prevention Technology
- RPT(R) Rust Prevention Technology for long lasting rust prevention.
- RPT® Rust Prevention Technology for long lasting rust prevention.
- Cooling Vanes
- Cooling vanes are coated to ensure vanes remain clear of rust and corrosion for optimal airflow and cooling.
- OE Matched
- OE Matched precision and performance.
- Non-Directional Finish
- A non-directional ground finish provides a product that is ready to install right out of the box.
RAYBESTOS 580756FZN Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.653 IN |
| Center Hole Diameter | 67.4 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 1.181 IN |
| Discard Thickness | 30 MM |
| Harmonize Code | 8708.30.5030 |
| Inside Diameter | 8.814 IN |
| Inside Diameter | 223.9 MM |
| Mounting Bolt Hole Circle Diameter | 4.724 IN |
| Mounting Bolt Hole Circle Diameter | 120 MM |
| Mounting Bolt Hole Diameter | 0.64 IN |
| Mounting Bolt Hole Diameter | 16.25 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 1.261 IN |
| Nominal Thickness | 32.05 MM |
| Outside Diameter | 13.978 IN |
| Outside Diameter | 355.05 MM |
| Overall Height | 1.958 IN |
| Overall Height | 49.75 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| Surface Type | Smooth |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00887213144765 |
RAYBESTOS 580756FZN Cross References
RAYBESTOS 580756FZN Fits Vehicles
- Chevrolet SS (2014-2017)
- Buick Regal (2012-2013)
- Chevrolet Camaro (2010-2015)
- Pontiac G8 (2009)
