(888) 312-8812 Login SignupCARTER FUEL PUMPS P76757M Fuel Pump Module Assembly
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
CARTER FUEL PUMPS P76757M Part Description
Manufacturer
Product Description
Fuel Pump Module Assembly
Features & Benefits
- Carter Electric Fuel Pumps and Electric Fuel Pump Assemblies are made with all new materials under rigorous quality controlled manufacturing and testing procedures.
- Quality Carter Electric Fuel Pumps and Fuel Pump Assemblies deliver optimum performance while providing long life.
- Most applications include the necessary accessories such as tank seals, patented high-gradient density strainers and wiring harnesses.
- Fuel sensor design provides resistance to corrosive fuel blends and additives.
CARTER FUEL PUMPS P76757M Specifications
Product Attributes
| Fuel Sending Unit Included | Yes |
| Voltage | 12 2H |
| Wiring Harness Length | 300.0 MM |
| Wire Gauge Measurement | 20 GU |
| Connector Color | White |
| Terminal Type | Blade |
| Mounting Hardware Included | No |
| Universal Or Specific Fit | Specific |
| Wire Quantity | 4 |
| Grade Type | Regular |
| Connector Shape | Trapezoid |
| Gasket Or Seal Included | Yes |
| Housing Material | POM |
| Terminal Quantity | 4 |
| Top Mount Diameter | 132.0 MM |
| Connector Gender | Female |
| Terminal Gender | Male |
| Strainer Included | Yes |
| Inlet Type | Port |
| Outlet Type | Quick Connect |
| Outlet Quantity | 1 |
| Fuel Filter Included | No |
| Minimum Pressure | 50.0 PS |
| Wire Harness Included | No |
| Outlet Fitting Thread Size | 5/16 IN |
| Minimum Flow Rating | 18 GPH |
| Pump Type | Electric |
| 65000 | No Proposition 65 warning is required with this product. |
| Average Current Draw | 8 68 |
| Average Flow Rating | 33.02 GPH |
| Connector Quantity | 1 |
| Fuel Tank Pressure Sensor Included | No |
| Fuel Type | N/A |
| Gasket Or Seal Material | Nitrile Rubber |
| Height | 9.41 IN |
| Height | 239 MM |
| Housing Length | 111 MM |
| Housing Length | 4.37 IN |
| Housing Width | 4.69 IN |
| Housing Width | 119 MM |
| In Tank or External | In Tank |
| Inlet Fitting Thread Size | N/A |
| Inlet Outside Diameter | 0.31 IN |
| Inlet Outside Diameter | 7.89 MM |
| Inlet Quantity | 1 |
| Installation Warnings | No |
| Internal or External | Internal |
| Lock Ring Included | No |
| Maximum Pressure | 50.75 PSI |
| Minimum Free Flow Rate | 52.83 GPH |
| Minimum Pressure | 40.6 PSI |
| Negative Ground | Yes |
| Outlet Outside Diameter | 0.31 IN |
| Outlet Outside Diameter | 7.89 MM |
| Outlet Thread Diameter | N/A |
Additional Information
| Country of Origin (Primary) | CN |
| Country of Origin 2 | MX |
| EAR99 | |
| Harmonized Tariff Code (HTS) | 8413309030 |
| Warranty Special | Limited Lifetime Warranty |
| Warranty Special UOM | TX |
| UPC | 00019826528292 |
| VMRS Code | 044003258 |
| UNSPSC | 40151532 |
CARTER FUEL PUMPS P76757M Cross References
| Brand | Part Number |
|---|---|
| 1-800-Radiator | 2920858 |
| AIRTEX | E9090M |
| Airtex Fuel Pumps | E9090M |
| Canadian Tire | 1234936 |
| Carquest Premium Fuel Pumps | M635706 |
| DELPHI | FG1969 |
| Import Direct Fuel Pumps | A33140 |
| N/A | E9090M, FE0543, 2920858, 77020-06302, 77020-06306, A33140, C0750M, SP9169M |
| NAPA Fuel Pumps | C0750M |
| Spectra Premium | SP9169M |
| Toyota | 77020-06302, 77020-06306 |
| TruGrade | B15112453TG |
CARTER FUEL PUMPS P76757M Fits Vehicles
- Toyota Avalon (2013-2018)
- Toyota Camry (2012-2017)
