RAYBESTOS 581032R Part Description
Manufacturer
Product Description
Raybestos R-Line Brake Rotor
Application Summary
2018-2014 Chevrolet Silverado 1500 Rear, 2018-2014 GMC Sierra 1500 Rear, 2020-2015 Chevrolet Tahoe Rear, 2020-2015 Chevrolet Suburban Rear, 2020-2015 GMC Yukon Rear, 2020-2015 GMC Yukon XL Rear, 2020-2015 Cadillac Escalade Rear
Features & Benefits
- OE Fit, Form, and Function
- Developed from OE samples and made with G3000-qualified material, ensuring OE fit, form and function for dependable braking.
- SAE Standard
- R-Line Rotors meet the SAE standard for tensile strength, providing structural integrity and a maximum service life.
- Low Initial Lateral Runout and Thickness Variation
- R-Line Rotors have a small parameter lateral runout and a thickness variation ensuring less pedal pulsation, less brake noise, and an extended pad life.
- Mill Balanced Edges
- R-Line Rotors are mill balanced and 100 percent validated. This helps minimize the thickness variation on the rotor and leads to minimized vibration and smoother stopping.
RAYBESTOS 581032R Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 3.09 IN |
| Center Hole Diameter | 78.5 MM |
| Conventional Or Drum-In-Hat Type Rotor | Drum-In-Hat |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Discard Thickness | 0.728 IN |
| Discard Thickness | 18.5 MM |
| Harmonize Code | 8708.30.5030 |
| Inside Diameter | 9.843 IN |
| Inside Diameter | 250 MM |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 5.5 IN |
| Mounting Bolt Hole Circle Diameter | 139.7 MM |
| Mounting Bolt Hole Diameter | 0.63 IN |
| Mounting Bolt Hole Diameter | 16 MM |
| Mounting Bolt Hole Quantity | 6 |
| Nominal Thickness | 0.787 IN |
| Nominal Thickness | 20 MM |
| Outside Diameter | 13.583 IN |
| Outside Diameter | 345 MM |
| Overall Height | 3.352 IN |
| Overall Height | 85.15 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 6 |
| Surface Type | Smooth |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708305030 |
| Canadian Harmonizing Tariff Code | 8708309990 |
| UPC | 00887213157352 |
RAYBESTOS 581032R Cross References
| Brand | Part Number |
|---|---|
| AutoZone | 55133DG, 55133DL, 55133P, 55133SD |
| BRAKEBEST | 521580RGS, 581032, 581032FZN, 581032P, 581032PER, 581032R |
| CENTRIC | 120.66065, 120.66065CRY, 121.66065, 126.66065CSL, 126.66065CSR, 126.66065SL, 126.66065SR, 127.66065CL, 127.66065CR, 127.66065L, 127.66065R, 128.66065CL, 128.66065CR, 128.66065L, 128.66065R, 227.66065L, 227.66065R, 320.66065 |
| Centric Parts | 120.66065, 120.66065CRY, 121.66065, 126.66065CSL, 126.66065CSR, 126.66065SL, 126.66065SR, 127.66065CL, 127.66065CR, 127.66065L, 127.66065R, 128.66065CL, 128.66065CR, 128.66065L, 128.66065R, 227.66065L, 227.66065R, 320.66065 |
| DURA CORP | BR5510302 |
| DuraGo | BR55133, BR5513302 |
| Dynamic Friction Company | 604-48053 |
| GM | 22775300, 23195438 |
| General Motors | 22775300, 23195438, 15792634, 22968231, 25832103, 84223345 |
| MAGMA PRODUCTS | PMR225268 |
| Performance Friction | 343.085.01 |
| Qualis | 55133 |
| TopNotch | TN580422GEO, TN581032GEO |
| WORLDPAC | 1407-86230, 1427-731729 |
| Winhere | 6621029 |
RAYBESTOS 581032R Fits Vehicles
- GMC Sierra 1500 Classic (2007)
- Chevrolet Cheyenne (2010-2017)
- GMC Sierra (2007-2014)
- GMC Yukon XL 1500 (2007-2014)
- Chevrolet Suburban 1500 (2007-2014)
- Chevrolet Avalanche (2007-2013)
- Cadillac Escalade EXT (2007-2013)
- GMC Sierra 1500 Limited (2019)
- Chevrolet Silverado 1500 LD (2019)
- GMC Yukon XL (2015-2020)
- Chevrolet Suburban (2014-2020)
- Chevrolet Tahoe (2007-2020)
- Cadillac Escalade ESV (2007-2020)
- Cadillac Escalade (2007-2020)
- GMC Yukon (2007-2020)
- GMC Sierra 1500 (2007-2019)
- Chevrolet Silverado 1500 (2007-2019)
