(888) 312-8812 Login SignupRAYBESTOS 781099R Raybestos R-Line Brake Rotor
MSRP: $97.92
$6399
Save $33.93
Limited availability at this price!
In Stock
Get it by Tuesday, Mar 17
RAYBESTOS 781099R Part Description
Manufacturer
Product Description
Raybestos R-Line Brake Rotor
Application Summary
2021-2014 Jeep Cherokee Rear, 2017-2015 Chrysler 200 Rear
Features & Benefits
- OE Fit, Form, and Function
- Developed from OE samples and made with G3000-qualified material, ensuring OE fit, form and function for dependable braking.
- SAE Standard
- R-Line Rotors meet the SAE standard for tensile strength, providing structural integrity and a maximum service life.
- Low Initial Lateral Runout and Thickness Variation
- R-Line Rotors have a small parameter lateral runout and a thickness variation ensuring less pedal pulsation, less brake noise, and an extended pad life.
- Mill Balanced Edges
- R-Line Rotors are mill balanced and 100 percent validated. This helps minimize the thickness variation on the rotor and leads to minimized vibration and smoother stopping.
RAYBESTOS 781099R Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.76 IN |
| Center Hole Diameter | 70.1 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Discard Thickness | 0.409 IN |
| Discard Thickness | 10.4 MM |
| Harmonize Code | 8708.30.5030 |
| Inside Diameter | 6.693 IN |
| Inside Diameter | 170 MM |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 4.331 IN |
| Mounting Bolt Hole Circle Diameter | 110 MM |
| Mounting Bolt Hole Diameter | 0.618 IN |
| Mounting Bolt Hole Diameter | 15.7 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.472 IN |
| Nominal Thickness | 12 MM |
| Outside Diameter | 10.945 IN |
| Outside Diameter | 278 MM |
| Overall Height | 1.307 IN |
| Overall Height | 33.2 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Solid |
| Stud/Lug Hole Quantity | 5 |
| Surface Type | Smooth |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00887213136951 |
RAYBESTOS 781099R Cross References
| Brand | Part Number |
|---|---|
| ADVANCE AUTO PARTS | YH514207P |
| AUTOPARTSOURCE | 491377 |
| AUTOXTRA | AX901272 |
| AUTOZONE | 72123, 72123DG |
| AutoZone | 72123DL |
| Autoxtra | AX901272P |
| BRAKEBEST | 16011617, 712064RGS, 781099, 781099FZN, 781099R |
| Brembo | 08.N282.11 |
| CENTRIC | 120.58013, 120.58013CRY, 121.58013, 126.58013SL, 126.58013SR, 127.58013L, 127.58013R, 128.58013L, 128.58013R, 320.58013 |
| CHRYSLER | 04779885AB, 4779885AB, 4779885AC |
| Centric Parts | 120.58013, 120.58013CRY, 121.58013, 126.58013SL, 126.58013SR, 127.58013L, 127.58013R, 128.58013L, 128.58013R, 320.58013 |
| DURA CORP | BR901272 |
| DuraGo | BR901272 |
| Dynamic Friction Company | 600-42012, 604-42012 |
| MAGMA PRODUCTS | PMR145204 |
| NEWTEK AUTOMOTIVE | R1272 |
| Newtek Automotive USA | R1272 |
| POWERSTOP | AR83089EVC |
| PROMAX | 14-630007 |
| Parts Master | 901272 |
| Qualis | 43192 |
| TopNotch | TN781099GEO |
| UAP | 2901272 |
| Ultra Brake | 51302 |
| WAGNER BRAKE | BD180651 |
| WORLDPAC | 1407-514207, 1427-731833 |
| Wagner Brake | BD180651E |
| Winhere | 6612064 |
RAYBESTOS 781099R Fits Vehicles
- Chrysler 200 (2015-2017)
- Jeep Cherokee (2014-2021)
