(888) 312-8812 Login SignupDELPHI AF10211 Mass Air Flow Sensor
MSRP: $211.58
$19799
Save $13.59
Limited availability at this price!
In Stock
Get it by Wednesday, Mar 4
DELPHI AF10211 Part Description
Manufacturer
Product Description
Mass Air Flow Sensor
Features & Benefits
- Delphi mass air flow sensors are the global benchmark for accuracy and signal noise
- Delphi mass air flow sensors feature high quality sensing elements for outstanding performance over a wide range of ambient temperatures
- Delphi is a manufacturer of OE mass air flow sensors since their first use over 30 years ago
- All parts are calibrated and tested to match the OE part
- Probe solution offered wherever possible to reduce repair time by eliminating the need to replace the flow tube
- Delphi OE technology validated to match the vehicle applications
DELPHI AF10211 Specifications
Product Attributes
| Item Grade | Premium |
| Package Contents | Mass Air Flow Sensor - Complete Assembly |
| Color | Black |
| Housing Included | Yes |
| Inlet Connection Diameter | 72 MM |
| Outlet Connection Diameter | 3.1 IN |
| Outlet Connection Diameter | 80 MM |
| Terminal Type | Blade |
| Mounting Hardware Included | No |
| Universal Or Specific Fit | Specific |
| Grade Type | Standard Replacement |
| Connector Quantity | 1 |
| Connector Shape | Rectangle |
| Mounting Hole Quantity | 4 |
| Housing Material | Plastic |
| Terminal Quantity | 4 |
| Connector Gender | Female |
| Terminal Gender | Male |
| Wiring Harness Included | No |
| Mounting Type | Bolt-On |
| Mounting Bracket Included | No |
| Inlet Connection Diameter | 2.8 IN |
| Sensor Casing Length | 120.7 MM |
| Sensor Casing Width | 111 MM |
| Voltage | 12.0 2H |
| Gasket Or Seal Included | Yes |
| Bolt Hole Center To Bolt Hole Center | 51.20 MM |
| Mounting Hole Diameter | 6.6 MM |
| Seal Outside Diameter | 89 mm |
| Seal Quantity | 1 |
| Sensor Casing Length | 4.7 IN |
| Sensor Casing Width | 4.3 IN |
| Bolt Hole Center To Bolt Hole Center | 2.00 IN |
| Mounting Hole Diameter | 0.2 IN |
| Seal Outside Diameter | 3.5 IN |
| Intake Air Temperature (IAT) Included | No |
Additional Information
| Warranty Distance UOM | DH |
| Warranty Distance | 12000 |
| Harmonized Tariff Code (Schedule B) | 9026800000 |
| Warranty Time UOM | MO |
| Warranty Time | 12 |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 9026802000 |
| UPC | 00689604231098 |
| VMRS Code | 045021019 |
| UNSPSC | 41111931 |
DELPHI AF10211 Cross References
| Brand | Part Number |
|---|---|
| ACDelco | 2131901, 2133368 |
| Airtex | 5S2712 |
| BWD | 221010M |
| Beck/Arnley | 158-0822 |
| Blue Streak Electronics New | MF21010N |
| Bosch | F00E000202, 63107 |
| CARDONE Reman | 74-10051 |
| Carquest | 64-1629, MQ7301 |
| Datsun/Nissan | 22680-30P00, B2680-30P00 |
| Dorman | 917-884, 917-883 |
| Duralast | DL-6020 |
| GLOBAL PARTS DISTRIBUTORS | 1813303 |
| N/A | 2268030P00, 213-1901, 213-3368, 245-1235 |
| NAPA Reman Computers | XTP410051 |
| NGK SPARK PLUGS | MG0115 |
| NTK | MG0115 |
| Richporter | MA237 |
| STANDARD IGNITION | MAS0150 |
| Spectra Premium | MA237 |
| Standard Motor Products | MF21010 |
| WAI | MAF10211T |
| WALKER PRODUCTS | 245-1235 |
| Wells | SU5069 |
DELPHI AF10211 Fits Vehicles
- INFINITI J30 (1993-1995)
- Nissan 300ZX (1990-1996)
