LETRIKA MS77 Starter 24V, 11T, CW, PLGR, Letrika/MAHLE AZG, 9kW, New

★★★★★ (0) Write a Review
MS77 by LETRIKA - Starter 24V, 11T, CW, PLGR, Letrika/MAHLE AZG, 9kW, New
LETRIKA

No Stock Available

We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.

We may have similar parts for sale. Search Alternatives >

LETRIKA MS77 Part Description

Manufacturer

LETRIKA

Technical Data
Product Starter
Letrika P/N IS1183
Voltage 24 V
Power 9.0 kW
OEM P/N 11.131.907
MAHLE P/N MS 77
Description AZG4689
No. of pinion teeth 11
Module 4.233 mm
Distance over two teeth 20.56 mm
Outside diameter of pinion 57 mm
Notes Insulated ground
Nominal power is 6,5kW according to ISO 8856
Noseless version of starter
Soft start relay
With reduction gear
Letrika P/N OEM P/N MAHLE P/N
IS1183 11.131.907 AZG4689 24V 9,0kW MS 77 Available
IS1183 11.131.655 AZG4663 24V 6,5kW Superseded unit, see available P/N IS1183
Related Parts
Letrika P/N MAHLE P/N DESCRIPTION POS
16.915.438 MSX 1003 Switch 4
16.915.439 MSX 1004 Supplementary switch 5
16.915.437 MSX 1016 Central cover 3
16.915.261 MSX 1047 Stator 12
16.915.263 MSX 1049 Set of brushes 14
16.915.269 MSX 1064 Armature 9
16.915.871 MSX 1098 Pinion 17
16.907.502 MSX 1308 Reduction gear 8
16.915.440 MSX 1402 Brush holder 13
16.907.862 MSX 1417 Drive end bracket 1
15.125.004 MSX 1672 Rear-end bracket 15
16.915.861 MSX 1709 Lever 7
16.908.340 MSX 305 Bearing 10
16.907.488 MSX 508 Fixing set 11

LETRIKA MS77 Cross References

BrandPart Number
IS1183
CATERPILLAR0R 2187, 0R 2190, 0R 4259, 104 7041, 104 7042, 106 8551, 1M 6132, 1N 9412, 3T 2651, 3T 2653, 3T 2784, 3T 5831, 3T 8952, 4N 0957, 4N 1062, 4N 5471, 5L 4171, 5L 4431, 5L 4513, 6N 1889, 6T 0643, 6V 0513, 6V 5539, 6V 5540, 7T 0796, 7T 9162, 8C 3645, 8L 8207, 9G 6096, 9G 6097, OR 2187, OR 2697, OR 4259, OR 4267, OR 5209, SL 8207
CUMMINS107 173, 126 405, 131 304, 135 160, 135 161, 135 162, 135 163, 147 923, 163 976, 167 072, 173 006, 173 007, 176 576, 179 753, 201 741, 3 021 036, 3 201 036, 3 328 552, 3 603 862, 3 604 321 RX, 3 604 658 RX, 3 632 274, 323 790, 41 897, 41 947, 42 584, 42 585, 42 586, 42 587, 43 491, 43 922, 44 043, 555 241, 555 388, 704 007, 705 620, 706 621, 706 622, 706 623, 707 860, 708 913, 708 914, 708 915, 708 916, 3604658RX, 147923
DELCO REMY10461024, 10461068, 10478937, 10478938, 10478943, 10478952, 10478980, 10478986, 10478990, 10478996, 10479010, 10479100, 10479114, 10479119, 10479142, 10479164, 10479339, 1108872, 1109788, 1109836, 1113708, 1113710, 1113717, 1113745, 1113748, 1113749, 1113778, 1113781, 1113783, 1113793, 1113813, 1113815, 1113818, 1113823, 1113824, 1113825, 1113831, 1113836, 1113842, 1113844, 1113845, 1113846, 1113850, 1113851, 1113853, 1113855, 1113858, 1113861, 1113862, 1113866, 1113872, 1113876, 1113883, 1113885, 1113887, 1113893, 1113894, 1113895, 1113898, 1113900, 1113902, 1113903, 1113905, 1113906, 1113914, 1113915, 1113916, 1113920, 1113925, 1113926, 1113934, 1113935, 1113948, 1113952, 1113955, 1113956, 1113957, 1113958, 1113965, 1113966, 1113968, 1113970, 1113971, 1113972, 1113976, 1113977, 1113978, 1113980, 1113981, 1113983, 1113991, 1113994, 1113995, 1113997, 1113999, 1114710, 1114715, 1114727, 1114728, 1114730, 1114737, 1114738, 1114755, 1114756, 1114760, 1114762, 1114790, 1114842, 1114846, 1114847, 1114848, 1114849, 1114850, 1114851, 1114852, 1114854, 1114855, 1114873, 1114874, 1114875, 1114878, 1114879, 1114880, 1114909, 1114915, 1114923, 1114935, 1114947, 1114950, 1114951, 1114958, 1114963, 1114964, 1114970, 1114979, 1990233, 1990234, 1990279, 1990291, 1990344, 1990361, 1990367, 1990368, 1990378, 1990382, 1990383, 1990384, 1990388, 1990390, 1990409, 1990410, 1990412, 1990416, 1990418, 1990422, 1990437, 1990444, 1990460, 1990461, 1990462, 1990485, 1990493, 1990842, 1993753, 1993805, 1993810, 1993828, 1993835, 1993842, 1993924, 1993941, 1993987, 8200330, DRS5167
DIXIE201-42202, TS-1503
DRESSER1219 523 H91
FARCOM103775
KOMATSU121 95 22 H92, 121 95 23 H91, 121 95 24 H91, 121 95 25 H92, 121 96 59 H92, 122 29 60 H91, 125 16 35 H92, STR 1015
LESTER18006, 18022, 3059, 3063, 3745, 3757, 3776, 3777, 3785, 3821, 3823, 3824, 3833, 3846, 4930, 5320, 6208, 6230, 6260, 6370, 6378, 6552, 6553, 6556, 6564, 6565, 6569, 6624
O&K1435554
ONAN (USA)191-1858, 191-2087
PRESTOLITEM125R3001SEP
RENAULT50 00 811 448
VOLVO11707118, 4078515, 9004078515, 9011707118
WHITEV1114251, V1115303
WILSON91-01-4159
ZETTELMEYER29016843
