(888) 312-8812 Login SignupLETRIKA MS418 Starter 12V, 10T, CW, Letrika/MAHLE AZJ, 2.7kW
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
LETRIKA MS418 Part Description
Manufacturer
Technical Data
| Product | Starter |
| Letrika P/N | IS0665 |
| Voltage | 12 V |
| Power | 2.7 kW |
| OEM P/N | 11.131.997 |
| MAHLE P/N | MS 418 |
| Description | AZJ3466 |
| No. of pinion teeth | 10 |
| Module | 2.54 mm |
| Distance over two teeth | 12.29 mm |
| Outside diameter of pinion | 32 mm |
| Notes | Oil sealed |
| Letrika P/N | OEM P/N | MAHLE P/N | |
|---|---|---|---|
| IS0665 | 11.131.997 AZJ3466 12V 2,7kW | MS 418 | Available |
| IS0665 | 11.130.665 AZJ3217 12V 2,7kW | Superseded unit, see available P/N IS0665 |
Related Parts
| Letrika P/N | MAHLE P/N | DESCRIPTION | POS |
|---|---|---|---|
| 16.915.919 | MSX 1726 | Switch | 4 |
| 16.905.973 | MSX 175 | Set of brushes | 14 |
| 16.906.171 | MSX 177 | Stator | 12 |
| 16.281.430 | MSX 198 | Drive end bracket | 1 |
| 16.905.972 | MSX 255 | Brush holder | 13 |
| 16.361.499 | MSX 326 | Armature | 9 |
| 16.905.853 | MSX 370 | Lever | 7 |
| 16.906.142 | MSX 371 | Fixing set | 11 |
| 16.281.899 | MSX 399 | Central cover | 3 |
| 15.120.243 | MSX 684 | Bearing | 2 |
| 16.905.481 | MSX 694 | Rear-end bracket | 15 |
| 15.120.155 | MSX 697 | Bearing | 10 |
| 16.903.166 | MSX 833 | Pinion with clutch | 6 |
LETRIKA MS418 Cross References
| Brand | Part Number |
|---|---|
| IS0665, MS 418 | |
| BOSCH | 0001362321, 0986020051, SR 587 X, SR 9938 X |
| CASE | A 186 180, R 393 41 |
| CNH/FIAT AGRI | A186180 |
| CUMMINS | 3 283 329, 3 283 330 |
| DAF | 1259961, 25-2067, 27564, 27595 |
| DENSO | 9702809-588, 9712809-021 |
| HELLA | 8EA 737 088-001, 8EA 737 266-001, CS 889, JS 1012 |
| JCB | 714/2590 |
| LESTER | 16658, 17037, 17232, 18065 |
| LEYLAND | S141 |
| LUCAS | LRS00706, S 1379 |
| MAGNETI MARELLI | 632 275 64 |
| MITSUBISHI | M3T90071 |
| PERKINS | OD203940 |
| PRESTOLITE | 20500706 |
| SPARE | X36219 |
