RAYBESTOS MGD1184ACH Part Description
Manufacturer
Product Description
Raybestos R-Line Ceramic Brake Pad Set
Application Summary
2022-2010 Toyota Prius Front, 2023 Toyota Corolla Front, 2017-2011 Lexus CT200h Front, 2019-2017 Toyota Prius Prime Front, 2015-2012 Toyota Prius Plug-In Front, 2022-2019 Toyota Prius AWD-e Front
Features & Benefits
- Ceramic and Semi-Metallic Formulations:
- Ceramic or semi-metallic materials consistent with OE fit, form, and function.
- Noise Dampening Shims
- Multi-layered steel shims for optimal noise damping.
- OE Matched Slots and Chamfers
- Slots & chamfers match OE design, allowing for less noise, vibration, and harshness.
- Hardware
- Hardware included, where applicable.
RAYBESTOS MGD1184ACH Specifications
Product Attributes
| FMSI Number | D1184-8538 |
| Friction Material Composition | Ceramic |
| Inner Pad Height | 1.960 in |
| Inner Pad Overall Thickness | 0.605 IN |
| Inner Pad Width | 4.830 in |
| Mounting Hardware Included | Yes |
| Outer Pad Height | 1.960 IN |
| Outer Pad Overall Thickness | 0.605 in |
| Outer Pad Width | 4.830 IN |
Additional Information
| Country of Origin (Primary) | MX |
| Canadian Harmonizing Tariff Code | 8708301900 |
| Harmonized Tariff Code (HTS) | 8708305040 |
| UPC | 00887213098648 |
RAYBESTOS MGD1184ACH Cross References
| Brand | Part Number |
|---|---|
| Bendix | CFC1184A, D1184A, SBC1184A |
| Bosch | BC1184A |
| BrakeBest | D1184A |
| Brembo | P83141N |
| MAGMA PRODUCTS | PMD1184AC |
| Newtek Automotive USA | SCD1184A |
| Perfect Stop | PC1184A |
| PowerStop | 16-1184A, 17-1184A, Z23-1184A |
| Toyota | 0446547060, 0446547070, 0446547080, 446547080, 044650W141 |
| Wagner Brake | D1184AC, OEX1184, OEX1184A, QC1184A, ZD1184A |
RAYBESTOS MGD1184ACH Fits Vehicles
- Toyota Corolla (2020-2022)
- Toyota Prius AWD-e (2019-2022)
- Toyota Prius Prime (2017-2019)
- Toyota Prius Plug-In (2012-2015)
- Lexus CT200h (2011-2017)
- Toyota Prius (2010-2022)
