(888) 312-8812 Login SignupRAYBESTOS 981042R Raybestos R-Line Brake Rotor
$8499
Limited availability at this price!
1 Day Lead Time
Get it by Thursday, Feb 26
RAYBESTOS 981042R Part Description
Manufacturer
Product Description
Raybestos R-Line Brake Rotor
Application Summary
2018-2015 Chevrolet City Express Front
Features & Benefits
- OE Fit, Form, and Function
- Developed from OE samples and made with G3000-qualified material, ensuring OE fit, form and function for dependable braking.
- SAE Standard
- R-Line Rotors meet the SAE standard for tensile strength, providing structural integrity and a maximum service life.
- Low Initial Lateral Runout and Thickness Variation
- R-Line Rotors have a small parameter lateral runout and a thickness variation ensuring less pedal pulsation, less brake noise, and an extended pad life.
- Mill Balanced Edges
- R-Line Rotors are mill balanced and 100 percent validated. This helps minimize the thickness variation on the rotor and leads to minimized vibration and smoother stopping.
RAYBESTOS 981042R Specifications
Product Attributes
| Center Hole Diameter | 2.677 IN |
| Center Hole Diameter | 68 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 1.024 IN |
| Discard Thickness | 26 MM |
| Harmonize Code | 8708.30.5030 |
| Inside Diameter | 7.008 IN |
| Inside Diameter | 178 MM |
| Mounting Bolt Hole Circle Diameter | 4.488 IN |
| Mounting Bolt Hole Circle Diameter | 114 MM |
| Mounting Bolt Hole Diameter | 4.488 IN |
| Mounting Bolt Hole Diameter | 114 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 1.102 IN |
| Nominal Thickness | 28 MM |
| Outside Diameter | 11.142 IN |
| Outside Diameter | 283 MM |
| Overall Height | 1.73 IN |
| Overall Height | 43.95 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Diameter | 4.488 IN |
| Stud/Lug Hole Diameter | 114 MM |
| Stud/Lug Hole Quantity | 5 |
| Surface Type | Smooth |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00887213094374 |
RAYBESTOS 981042R Cross References
RAYBESTOS 981042R Fits Vehicles
- Chevrolet City Express (2015-2018)
