(888) 312-8812 Login SignupRAYBESTOS 980948R Raybestos R-Line Brake Rotor
$8649
Limited availability at this price!
1 Day Lead Time
Get it by Wednesday, Mar 11
RAYBESTOS 980948R Part Description
Manufacturer
Product Description
Raybestos R-Line Brake Rotor
Application Summary
2015-2011 Volkswagen Jetta Front
Features & Benefits
- OE Fit, Form, and Function
- Developed from OE samples and made with G3000-qualified material, ensuring OE fit, form and function for dependable braking.
- SAE Standard
- R-Line Rotors meet the SAE standard for tensile strength, providing structural integrity and a maximum service life.
- Low Initial Lateral Runout and Thickness Variation
- R-Line Rotors have a small parameter lateral runout and a thickness variation ensuring less pedal pulsation, less brake noise, and an extended pad life.
- Mill Balanced Edges
- R-Line Rotors are mill balanced and 100 percent validated. This helps minimize the thickness variation on the rotor and leads to minimized vibration and smoother stopping.
RAYBESTOS 980948R Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.559 IN |
| Center Hole Diameter | 65 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 0.748 IN |
| Discard Thickness | 19 MM |
| Harmonize Code | 8708.30.5030 |
| Inside Diameter | 7.024 IN |
| Inside Diameter | 178.4 MM |
| Mounting Bolt Hole Circle Diameter | 4.409 IN |
| Mounting Bolt Hole Circle Diameter | 112 MM |
| Mounting Bolt Hole Diameter | 4.409 IN |
| Mounting Bolt Hole Diameter | 112 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.862 IN |
| Nominal Thickness | 21.9 MM |
| Outside Diameter | 11.02 IN |
| Outside Diameter | 279.9 MM |
| Overall Height | 1.953 IN |
| Overall Height | 49.6 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| Surface Type | Smooth |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00829352976180 |
RAYBESTOS 980948R Cross References
| Brand | Part Number |
|---|---|
| ADVANCE AUTO PARTS | YH326332P |
| AUTOZONE | 78012DG |
| Advance Auto Parts | YH326332, YH326332C |
| AutoZone | 78012 |
| BENDIX | PRT6154 |
| BRAKEBEST | 980948, 980948R, 980948RGS |
| CENTRIC | 120.33132, 121.33132, 125.33132, 126.33132CSL, 126.33132CSR, 126.33132SL, 126.33132SR, 127.33132L, 127.33132R, 128.33132L, 128.33132R, 320.33132C |
| Centric Parts | 120.33132, 121.33132, 125.33132, 126.33132CSL, 126.33132CSR, 126.33132SL, 126.33132SR, 127.33132L, 127.33132R, 128.33132L, 128.33132R, 320.33132C |
| DURA CORP | BR34501 |
| Dura Corp | BR901074 |
| DuraGo | BR901074 |
| MAGMA PRODUCTS | PMR583089 |
| NEWTEK AUTOMOTIVE | 34501 |
| Newtek Automotive USA | 34501 |
| PROMAX | 14-34501 |
| Qualis | 45571 |
| VOLKSWAGEN | 5C0615301 |
| WINHERE | 662957 |
| WORLDPAC | 1407-326332, 1427-731856 |
| WORLDPARTS | WS1-734501 |
| Wagner Brake | BD180523E |
RAYBESTOS 980948R Fits Vehicles
- Volkswagen Golf (2014)
- Volkswagen Caddy (2014-2015)
- Volkswagen Bora (2005-2010)
- Volkswagen Beetle (2019)
- Seat Leon (2006-2012)
- Seat Freetrack (2010-2014)
- Seat Altea (2006, 2010-2012)
- Volkswagen Jetta (2011-2016)
