(888) 312-8812 Login SignupRAYBESTOS 97831R Raybestos R-Line Brake Drum
$24299
Limited availability at this price!
1 Day Lead Time
Get it by Thursday, Mar 5
RAYBESTOS 97831R Part Description
Manufacturer
Product Description
Raybestos R-Line Brake Drum
Application Summary
1993-1987 Isuzu NPR Front, 2018-1987 Isuzu NPR Rear, 2008-1995 GMC W3500 Forward Rear, 2009-1995 Chevrolet W3500 Tiltmaster Rear, 1993-1992 GMC W4500 Forward Front, 1997-1992 GMC W4500 Forward Rear, 2015-2011 Isuzu Reach Rear
Features & Benefits
- OE Fit, Form, and Function
- Developed from OE samples and made with G3000-qualified material, ensuring OE fit, form and function for dependable braking.
- SAE Standard
- R-Line Drums meet the SAE standard for tensile strength, providing structural integrity and a maximum service life.
- Mill Balanced Edges
- R-Line Drums are mill balanced and 100 percent validated. This helps minimize the thickness variation on the rotor and leads to minimized vibration and smoother stopping.
- CNC Machined
- R-Line Drums are CNC machined for precise fitment
RAYBESTOS 97831R Specifications
Product Attributes
| Bolt Thread Pitch | 0.886 IN |
| Bolt Thread Pitch | 22.5 MM |
| Depth | 3.626 IN |
| Depth | 92.1 MM |
| Nominal Drum Diameter | 12.598 IN |
| Nominal Drum Diameter | 320 MM |
| Outside Diameter | 14.567 IN |
| Outside Diameter | 370 MM |
| Stud/Lug Hole Diameter | 0.886 IN |
| Stud/Lug Hole Diameter | 22.5 MM |
| Stud/Lug Hole Quantity | 6 |
Additional Information
| Country of Origin (Primary) | CN |
| UPC | 00887213096446 |
RAYBESTOS 97831R Cross References
| Brand | Part Number |
|---|---|
| BRAKEBEST | 97831R |
| CENTRIC | 123.76001 |
| ISUZU | 8973190550 |
| Qualis | 24244 |
RAYBESTOS 97831R Fits Vehicles
- Chevrolet W4500 Tiltmaster (1987-1996)
- GMC W4500 Forward (1992-1997)
- Isuzu Reach (2011-2015)
- Isuzu NPR (1987-2018)
- GMC W3500 Forward (1995-2008)
- Chevrolet W3500 Tiltmaster (1995-2009)
