NGK SPARK PLUGS BPR2ES BLYB Part Description
Manufacturer
Product Description
NGK Standard Carded Spark Plug
Features & Benefits
- ACTUAL OE or EQUIVALENT DESIGN: OEM quality construction nickel alloy center electrode provides consistent performance
- RECOMMENDED USAGE: Best for vehicles with OE nickel alloy plugs, not recommended on vehicles with factory precious metal plugs
- NGK's OE CERAMIC TECHNOLOGY: High grade alumina silicate ceramic creates a stronger insulator for optimal dielectric performance
- SOLID COPPER CORE: 98% pure copper core offers superior heat dissipation, conductivity and ultra wide heat ranges
- COLD-ROLLED THREADS: Prevents cross-threading and damage to cylinder heads
- TRIVALENT METAL PLATING: Delivers superior anti-corrosion and anti-seizing properties, ensuring ease of installation and removal
NGK SPARK PLUGS BPR2ES BLYB Specifications
Product Attributes
| Part Number | BPR2ES BLYB |
| Short Style Spark Plug | No |
| Service Number | BPR2ES BLYB |
| Stock Number | 6770 |
| Resistance | 5000.0 82 |
| Ground Electrode Tip Design | Standard |
| Ground Configuration | J-Gap |
| Ground Electrode Core Material | Nickel |
| Washer(s) Included | Yes |
| Grade Type | Standard Replacement |
| Electrical Terminal Type | Non-Removable Nut |
| Center Electrode Core Material | Copper |
| Center Electrode Tip Material | Nickel |
| Pre-Gap Size | .032 IN |
| Ground Electrode Quantity | 1 |
| Hex Size | 13/16" |
| Insulator Height | 2.20 IN |
| Manufacturer Heat Range | 2 |
| Seat Type | Flat |
| Reach | 0.750 IN |
| Thread Diameter | 0.551 IN |
| Insulator Material | Ceramic |
| Resistor Type | Yes |
| Skirt Length | 0.0 IN |
| Ground Electrode Tip Material | Nickel |
| Skirt | No |
| Center Electrode Insulator Tip Projection | 0.18 IN |
| Center Electrode Design | Standard |
| Washer Type | Crush |
| Center Electrode Projection | Long Projection |
| Metallurgy | Copper |
| Thread Type Standard | Metric |
| Pre-Gap Size | 0.8 MM |
| Insulator Height | 56.0 MM |
| Reach | 19.0 MM |
| 6648 | 0.0 MM |
| Thread Size | M14 - 1.25 |
| Center Electrode Insulator Tip Projection | 4.5 MM |
Additional Information
| Harmonized Tariff Code (HTS) | 8511100000 |
| Warranty Time UOM | MO |
| Warranty Time | 2 |
| Country of Origin (Primary) | JP |
| UPC | 00087295067703 |
| VMRS Code | 033003005 |
| UNSPSC | 26101732 |
NGK SPARK PLUGS BPR2ES BLYB Cross References
| Brand | Part Number |
|---|---|
| Autolite | 66, 66BP, 66DP2 |
| Champion Spark Plug | 105, RN16YC5 |
| DENSO Auto Parts | 6044, W9EXR-U, 6005, 6046, W9EXU, W9EP |
| Honda | 98079-52876 |
| John Deere | M138938 |
| Kawasaki | 92070-2110 |
| Kubota | 12681-6771-1 |
| N/A | BPR2ES BLYB |
| NGK | 6770 |
| Yamaha | 94702-00348, 94709-00348 |
| Yanmar | 160798-78010 |
NGK SPARK PLUGS BPR2ES BLYB Fits Vehicles
- Kawasaki KAF620 Mule 4010 Trans 4x4 FE (2021-2024)
- Kawasaki KAF620 Mule 4010 4x4 FE (2021-2024)
- Kawasaki KAF620 Mule 4000 Trans (2018-2021)
- Yamaha DR2A The Drive2 Super Hauler EFI (2019)
- Yamaha DR2A The Drive2 Concierge 4 EFI (2019)
- Yamaha DR2A The Drive2 Concierge 6 EFI (2019)
- Yamaha DR2A The Drive2 Adventurer Sport 2+2 EFI (2019)
- Yamaha YTF-1A Adventurer Sport 2+2 (2018)
- Yamaha YTF-2A Fairway Lounge (2014-2018)
- Yamaha YTF-2A Adventurer Two (2017-2018)
- Yamaha YTF-1A Adventurer Sport (2014-2018)
- Yamaha YTF-1A Adventurer One (2014-2018)
- Yamaha YTF-1A Adventurer 2+2 (2014-2017)
- Yamaha YDR-A The DRIVE PTV EFI (2014-2016)
- Yamaha YDR-A The DRIVE EFI (2013-2016)
- Yamaha YDR-A Concierge 6-Passenger (2014-2018)
- Yamaha YDR-A Concierge 4-Passenger (2014-2016)
- Yamaha YDR-A Adventurer Super Hauler (2016-2018)
- John Deere Gator HPX 615E (2018)
- Yamaha DR2A The Drive2 PTV EFI (2017-2019)
- Yamaha DR2A The Drive2 Fleet EFI (2017-2019)
- Yamaha DR2A The Drive2 Fleet Carb (2017-2018)
- Kawasaki KAF620 Mule 4010 Trans 4x4 Camo (2014-2023)
- Yamaha YTF-2 Fairway Lounge (2011)
- Yamaha YDR-A SVL Concierge 6-Passenger (2009-2011)
- Yamaha YDR-A SVS Concierge 4-Passenger (2009-2011)
- Yamaha YDR-A The DRIVE PTV (2010-2016)
- Yamaha YTF-2 Adventurer Two (2009-2013)
- Yamaha YTF-1 Adventurer One (2009-2013)
- Yamaha YDR-A The DRIVE (2007-2016)
- Yamaha G28-A U-MAX Medium Duty II (2004, 2006-2009)
- Yamaha G23-A U-MAX Medium Duty I (2004, 2006-2009)
- Yamaha G27-A U-MAX Light Duty (2004, 2006-2008)
- Yamaha G22-A G-MAX (2003-2007)
- Yamaha G14-A Ultima (1995-1996)
- Yamaha G21-A (2000-2004)
- Yamaha G16-A Ultima (1996-1997, 2000-2002)
- Yamaha G20-A Concierge (2000-2002)
- Yamaha G11-A Yamahauler (1996, 2001)
- Kawasaki KAF620 Mule 4010 Trans 4x4 SE (2016-2018)
- Kawasaki KAF620 Mule 4010 4x4 SE (2016-2018)
- Kawasaki KAF620 Mule 3020 (2001-2003)
- Kawasaki KAF620 Mule 3010 Trans 4x4 (2005)
- Kawasaki KAF620 Mule 3010 4x4 (2001-2005)
- Kawasaki KAF620 Mule 3000 (2001-2005)
- Kawasaki KAF620 Mule 4010 Trans 4x4 (2009-2024)
- Kawasaki KAF620 Mule 4000 (2009-2023)
- Kawasaki KAF620 Mule 4010 4x4 (2009-2024)
- John Deere Gator XUV 625i 4x4 (2011-2016)
- John Deere Gator TX 4x2 (2010-2017)
- John Deere Gator XUV 620i 4x4 (2010)
- John Deere Gator TS 4x2 (2010-2017)
- John Deere Gator TH 6x4 (2010-2016)
- John Deere Gator HPX 4x4 (2010-2016)
- Yamaha YXP1000A Pro Hauler 1000 (2004-2005)
- Yamaha YXP700A Pro Hauler 700 (2004-2006)
