PETERSON LIGHTING 904-MV Part Description
Manufacturer
Product Description
LED WORK LIGHT, SQUARE, PEDESTAL-MOUNT, 700 LUMEN, 3"X3", MV
Features & Benefits
- 3" X 3" Square Work Light
- Rugged, die-cast aluminum body with heat dissipating fins.
- Color Temperature: 6300k
- Multi-volt circuitry is compatible with 12V and 24V vehicles.
- Hardwired design with 2-wire PVC jacketed harness.
- Draws 0.98A @ 12V, 0.43A @ 24V.
- Certified to ECE Reg 10.
- Certified to meet IP67 ingress protection rating.
- Stainless steel mounting hardware.
- 750 lumens output.
904 Great White® 3"x3" LED Square Work Light
Features & Benefits
- 4 High-output Great White® diodes for a bright, even flood pattern
- Impact-resistant polycarbonate lens
- Die-cast aluminum body with matte black finish
- Heat dissipating fins for durability and longevity
- High vibration resistance and low amp draw
- Compatible with both 12 and 24-volt systems
- 9–36 VDC operating range
- Reverse voltage protection
- Draws 0.98A @ 12V, 0.43A @ 24V
- 2-Conductor black PVC jacketed harness 20 GA GPT.
- Operating temperature: -40° – +65° C
- Color temperature: 6300k
- EMC approval R10 and R23
- IP67 rated
- Stainless steel mounting hardware
PETERSON LIGHTING 904-MV Specifications
Product Attributes
| Beam Pattern | flood |
| Bulb Technology | LED |
| Bulb/diode Count | 4 |
| California Prop65 Required | Y |
| Coil Cord | N |
| Color Temperature | 6300k |
| Container Type | box |
| Exterior Use | Y |
| Height | 3.78 in |
| Integral Switch | N |
| Length | 2.83 in |
| Lens Color | clear |
| Light Color | white |
| Maximum Voltage | 36 Volts |
| Minimum Voltage | 9 Volts |
| Mounting Type | stud |
| Multi-volt | Y |
| Regulatory Compliance | ECE |
| Shape | square |
| Submersible | N |
| Termination | stripped wire |
| Voltage | 12V / 24V |
| Width | 1.56 in |
| Brightness | 750 LU |
Additional Information
| Warranty Special | See full warranty terms: https://pmlights.com/warranty |
| Warranty Special UOM | TX |
| Warranty Time | 3 |
| Warranty Time UOM | YR |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (Schedule B) | 8512202000 |
| UPC | 00044464993379 |
| VMRS Code | 053006293 |
PETERSON LIGHTING 904-MV Cross References
PETERSON LIGHTING 904-MV Customer Reviews
No reviews yet
Be the first to review this product!
PETERSON LIGHTING 904-MV Manufacturer Information
Peterson Lighting® is a family-owned company that produces and distributes vehicle safety lighting systems mirrors, and other related safety products and accessories. It has been in the business for 75 years, and currently, it offers over 2,200 products designed for various applications, including tilt-bed and cargo vehicles and light- and medium-duty trailers. Peterson Lighting believes that full commitment to quality is its responsibility as a market leader. All its components are designed and manufactured only in its ISO 9001/QS-9000-certified facility in Grandview, MO. This facility is handled by knowledgeable and highly skilled specialists, who are as dedicated and passionate as the company when it comes to quality.
