(888) 312-8812 Login SignupMONROE 37339 OESpectrum® Suspension Shock Absorber - Gas Charged, for 2009-2015 Honda Pilot
Tap to view 5 more
MSRP: $104.20
$6449
Save $39.71
Limited availability at this price!
In Stock
Get it by Thursday, Feb 12
MONROE 37339 Part Description
Manufacturer
Product Description
OESpectrum® Suspension Shock Absorber - Gas Charged, for 2009-2015 Honda Pilot
Application Summary
2009-2015 Honda Pilot
Features & Benefits
- EXCEPTIONAL HANDLING -- Full displaced valving, tuned specifically to each vehicle, adjusts to road extremes while the larger bore provides more efficient damping control to provide consistency and a smooth ride
- CONTROL AND DURABILITY -- PTFE-banded piston provides consistent sealing between piston and pressure tube for better control and increased durability
- REDUCED NOISE, VIBRATION AND HARSHNESS -- Twin Technology™ Active Control System delivers exceptional control under most driving conditions while isolating impact-related noise, vibration and harshness
- IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
- CONSISTENT RIDE -- OE all-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown
- BUILT TO LAST -- Self-lubricating fluid seal retains gas and reduces excessive friction against the piston rod to help reduce premature wear
- BUY WITH CONFIDENCE -- Comes with Monroe’s Limited Lifetime Warranty and exclusive Feel the Difference™ Guarantee
- BUY WITH CONFIDENCE -- Comes with Monroe's Limited Lifetime Warranty and exclusive Feel the DifferenceTM Guarantee
MONROE 37339 Specifications
Product Attributes
| Lower Mount Code | LS20 |
| Upper Mount Code | XP15 |
| Dust Shield Included | Yes |
| Includes Bump Stop | No |
| Internal Rebound Bumper | Yes |
| Hydraulic Lockout | No |
| Part Description | Shock Absorber |
| Compressed Length | 13.33 IN |
| Extended Length | 21.52 in |
| Gas Charged | Yes |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 7/16" Sleeve ID X 3.3/8" Sleeve OAL |
| Parts Pack(s) | None |
| Travel Length | 8.19 in |
| Upper Mount Type | XP15 |
| Compressed Length | 338.6 MM |
| Extended Length | 546.6 MM |
| Travel Length | 208 MM |
| Upper Mount Type | Cross Pin Mount - Closed Ended, 1/2" Hole ID (Both Ends) X 3 3/4" Pin Length (Hole Center to Center) |
| Shock Absorber Rod End Measuring Point | Center of Cross Pin |
| Shock Absorber Body End Measuring Point | Center of Loop |
| Lower Mount Type | Loop (Eyelet) Bushing and Sleeve |
| Lower Mount Code | LS20 |
| Upper Mount Code | XP15 |
| Mounting Hardware Included | No |
| Grade Type | Premium |
| Active or Passive Suspension | Passive |
| Adjustable Compression | No |
| Adjustable Rebound | No |
| Adjustable Ride Height | No |
Additional Information
| MSDS Sheet Number | 01168 |
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708800050 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598147592 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
MONROE 37339 Cross References
| Brand | Part Number |
|---|---|
| 37339ST, FT4Z5827411CB | |
| Duralast | TS3439472B |
| FCS | 342873 |
| FCS AUTO PARTS | 342873 |
| GABRIEL | G64104 |
| Gold Shock Absorber | 9150663 |
| Honda | 51605SZAA02, 51606SZAA02, 52610SZAA04, 52610SZAA51 |
| KYB | 349151 |
| KYB AMERICA LLC. | 349151 |
| MasterPro Shocks and Struts | HN106 |
| Monroe Shocks & Struts | 210323 |
| NAPA Shocks | 37339, NS37339 |
| OEM | 52610SZAA51, 52610SZAA04 |
| SENSEN | 1213-0546 |
| Sensen | 12130546 |
| Top Quality | 7837339 |
| UNITY AUTOMOTIVE | 250040, 2-250040-001, 4-11645-250040-001 |
| Ultra Spring Seat | G64104 |
MONROE 37339 Fits Vehicles
- Honda Pilot (2009-2015)
