GATES 2/9710PB Part Description
Manufacturer
Product Description
Green Stripe PowerBand Heavy-Duty Joined V-Belt
Application Summary
1993-1990 Ford, LN8000, Ford 6-Cyl. 7.8 L Diesel, Fan & Alt.
Features & Benefits
- Unique tensile cord design gives belt extra strength, added flexibility and shock-load resistance
- Molded notches reduce bending stress, especially on small diameter pulleys, while dissipating heat
- Even load distribution between strands provides better shock-load absorption
- Eliminates belt turnover or belts jumping off the drive
- Meets or exceeds SAE J636 specifications
- Meets RMA oil and heat resistant standards and static conductivity requirements
GATES 2/9710PB Specifications
Product Attributes
| Type | High Capacity Joined V-Belt |
| Cross Section Designation | HC50 |
| Angle | 36 |
| Strand Quantity | 2 |
| Top Width | 1.125 in |
| Top Width Per Strand | .5 IN |
| Outside Circumference | 71.86 in |
| Effective Length | 70.98 in |
| Construction | Notched |
| Notched | Yes |
| Belt Material | EPDM |
| Cord Material | Polyester |
| Top Width | 28 mm |
| Top Width Per Strand | 13 MM |
| Outside Circumference | 1825 mm |
| Effective Length | 1803 mm |
Additional Information
| Harmonized Tariff Code (Schedule B) | 4010343000 |
| Country of Origin (Primary) | US |
| Stock Status | N |
| UPC | 00072053114409 |
| VMRS Code | 065005003 |
| UNSPSC | 26111801 |
GATES 2/9710PB Cross References
| Brand | Part Number |
|---|---|
| 85410032 | |
| ACDelco | 2T17710 |
| CARQUEST | 2/9710PB |
| DAYCO | 17710 |
| Ford | E8HT 8620 B |
| John Deere | AT158366 |
| NAPA | 25-18035-2 |
| NAPA Belts/Hose | 25-9710-2 |
| Volvo White | 208043832 |
GATES 2/9710PB Fits Vehicles
- Peterbilt 320 (1992-1995)
- Ford LN7000 (1990)
- Ford LT9000 (1990-1991)
- Ford LN8000 (1990-1993)
- Ford LS8000F (1991)
- Ford LT8000F (1990-1992)
- Ford LTS8000F (1990-1992)
- Ford FT900 (1990-1993)
- Ford LNT8000F (1990-1993)
- Ford LTL9000 (1990-1991)
- Ford LTS9000 (1990-1991)
- Ford LA8000F (1991-1993)
- Ford LTA9000 (1990-1991)
- Ford B-700 (1990-1993)
