(888) 312-8812 Login SignupGATES 2/9325PB Green Stripe PowerBand Heavy-Duty Joined V-Belt
Tap to view 1 more
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
GATES 2/9325PB Part Description
Manufacturer
Product Description
Green Stripe PowerBand Heavy-Duty Joined V-Belt
Application Summary
1996 Peterbilt, 379, Detroit Diesel 6-Cyl. 12.7 L Diesel, Alt.
Features & Benefits
- Unique tensile cord design gives belt extra strength, added flexibility and shock-load resistance
- Molded notches reduce bending stress, especially on small diameter pulleys, while dissipating heat
- Even load distribution between strands provides better shock-load absorption
- Eliminates belt turnover or belts jumping off the drive
- Meets or exceeds SAE J636 specifications
- Meets RMA oil and heat resistant standards and static conductivity requirements
GATES 2/9325PB Specifications
Product Attributes
| Type | High Capacity Joined V-Belt |
| Cross Section Designation | HC50 |
| Angle | 36 |
| Strand Quantity | 2 |
| Top Width | 1.125 in |
| Top Width Per Strand | .5 IN |
| Outside Circumference | 33.55 in |
| Effective Length | 32.67 in |
| Construction | Notched |
| Notched | Yes |
| Belt Material | EPDM |
| Cord Material | Polyester |
| Top Width | 28 mm |
| Top Width Per Strand | 13 MM |
| Outside Circumference | 852 mm |
| Effective Length | 830 mm |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 4010323000 |
| Stock Status | N |
| UPC | 00072053184655 |
| VMRS Code | 065005003 |
| UNSPSC | 26111801 |
GATES 2/9325PB Cross References
| Brand | Part Number |
|---|---|
| 85410101 | |
| ACDelco | 2T17325 |
| Alliance Truck Parts | GT2/9325PB, GT2PB17325 |
| CARQUEST | 2/9325PB |
| DAYCO | 17325 |
| Dynacraft | D11049544 |
| Goodyear | 2/17315TT |
| NAPA Belts/Hose | 25-9325-2 |
GATES 2/9325PB Fits Vehicles
- Peterbilt 378 (1996)
- Peterbilt 379 (1996)
- Peterbilt 377 (1996)
- Peterbilt 362 (1994-1996)
- Kenworth W900 (1996)
- Kenworth K100E (1994-1996)
