MONROE 71124 Part Description
Manufacturer
Product Description
Reflex Suspension Strut
Features & Benefits
- IMPROVES STABILITY -- ASD (Acceleration Sensitive Damping) valving technology adjusts to impacts, reducing roll and dive for vehicles with a higher center of gravity
- EXCEPTIONAL HANDLING -- Rod displaced valving, tuned specifically to each vehicle, adjusts to road extremes to provide consistency and a smooth ride (on most applications)
- CONTROL AND DURABILITY -- Fluon-banded piston provides consistent sealing between piston and pressure tube for better control and increased durability
- IMPROVES PERFORMANCE -- Nitrogen gas charge maintains tire-to-road contact for improved ride and handling by reducing aeration
- CONSISTENT RIDE -- OE all-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown
- OPTIONAL DUST BOOT/JOUNCE BUMPER -- Protective dust boot reduces dirt and moisture, while jounce bumper helps prevent severe suspension movement (both sold separately)
- LONGER SERVICE LIFE -- Bronze reinforced rod guide bearing and special single lip seal combined with hardened, chrome-plated piston rod provides durability and longer service life
- BUY WITH CONFIDENCE -- Comes with Monroe's Limited Lifetime Warranty and exclusive Feel the Difference™ Guarantee
MONROE 71124 Specifications
Product Attributes
| Compressed Length | 19.32 IN |
| Extended Length | 20.42 in |
| Travel Length | 1.1 in |
| Body Length | 18.82 IN |
| Body Type | SS2 |
| Dust Shield Included | No |
| Includes Bump Stop | Yes |
| Internal Rebound Bumper | Yes |
| Strut Charging Type | Gas Charged Unit - Strut Rod Will Extend Automatically |
| Parts Pack(s) | P01611 |
| Mounting Hardware Included | Yes |
| Body Diameter | 2 IN |
| Compressed Length | 490.7 MM |
| Extended Length | 518.7 MM |
| Travel Length | 27.9 MM |
| Gas Charged | Yes |
| Body Length | 478 MM |
| Body Diameter | 50.8 MM |
Additional Information
| MSDS Sheet Number | 1164 |
| Country of Origin (Primary) | US |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708801600 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598019844 |
| UNSPSC | 25172007 |
MONROE 71124 Cross References
| Brand | Part Number |
|---|---|
| 71124ST, GA8Z7463805AA | |
| Duralast | ST3315031B |
| FCS | 345687 |
| FCS Auto Parts | 345687 |
| Ford | 6L2Z18124A, 6L2Z18124AA, 6L2Z18124AB, 6L2Z18124B, 6L2Z18124BA, 6L2Z18124BB, 6L2Z18125AA, 6L2Z18125BA, 7A2Z18124D, 7A2Z18124DB, 7A2Z18124E, 7A2Z18124EB, 7A2Z18124F, 7A2Z18124FB, 7A2Z18125D, 7A2Z18125DB, 7A2Z18125E, 7A2Z18125EB, 7A2Z18125F, 7A2Z18125FB, 7L2Z18124AA, 7L2Z18124AB, 7L2Z18124B, 7L2Z18124BB, 7L2Z18125A, 7L2Z18125AB, 7L2Z18125B, 7L2Z18125BB |
| Gabriel | G52205, G56838 |
| KYB | 341474 |
| KYB AMERICA LLC. | 341474 |
| Mercury | 6L2Z18124A, 6L2Z18124AA, 6L2Z18124AB, 6L2Z18124B, 6L2Z18124BA, 6L2Z18124BB, 6L2Z18125AA, 6L2Z18125BA, 7L2Z18124AA, 7L2Z18124AB, 7L2Z18124B, 7L2Z18124BB, 7L2Z18125A, 7L2Z18125AB, 7L2Z18125B, 7L2Z18125BB |
| NAPA Shocks | 71124 |
| OEM | 6L2Z18124A, 7A2Z18124EB, 7L2Z18124B, 6L2Z18124AB, 6L2Z18124B, 6L2Z18124BB, 6L2Z18124BA, 7A2Z18124FB, 7A2Z18124DB, 6L2Z18124AA, 7L2Z18124AA, 7L2Z18124BB, 7L2Z18124AB |
| PRT | 374110 |
| Rancho | RS5753, RS55753 |
| Sensen | 3214-0168, 32140168 |
| Top Quality | 7871124 |
MONROE 71124 Fits Vehicles
- Ford Explorer Sport Trac (2007-2010)
- Mercury Mountaineer (2006-2010)
- Ford Explorer (2006-2010)
