(888) 312-8812 Login SignupDELPHI ES20009 Oxygen Sensor
$13349
Limited availability at this price!
In Stock
Get it by Friday, Mar 13
DELPHI ES20009 Part Description
Manufacturer
Product Description
Oxygen Sensor
Features & Benefits
- Delphi planar technology covers older, conical design sensors
- Smart design consolidates SKUs without using long wires
- Patented protective sensor coating helps prevent contamination
- Validated for all fuel types, including ethanol blends like E85
- OE tested to 150,000 miles, plus 2,000 hours severe thermal testing
- Delphi is a global OE manufacturer for oxygen sensor and all oxygen sensors are built to Delphi's OE standards
DELPHI ES20009 Specifications
Product Attributes
| Package Contents | Oxygen Sensor, Instruction Sheet |
| Position(s) | Front, Rear Left. For the position specific to your vehicle, refer to the Applications. |
| Wiring Harness Length | 22.0 IN |
| Wiring Harness Length | 560.0 MM |
| Sensor Type | Narrow-Band |
| Terminal Type | Blade |
| Universal Or Specific Fit | Specific |
| Band Type | Narrow |
| Wire Quantity | 4 |
| Grade Type | Standard Replacement |
| Connector Shape | Trapezoid |
| Terminal Quantity | 4 |
| Connector Gender | Female |
| Terminal Gender | Male |
| Thread Diameter | 0.7 IN |
| Wrench Size | 22mm |
| Thread Size | M18 - 1.5 |
| Overall Length | 23.2 IN |
| Overall Length | 590.0 MM |
| Mounting Type | Threaded |
| Thread Diameter | 18.0 MM |
| Wire Gauge Measurement | 20.0 GU |
| Thread Type Standard | Metric |
| Heated | Yes |
Additional Information
| Warranty Distance UOM | DH |
| Warranty Distance | 12000 |
| Harmonized Tariff Code (Schedule B) | 9027100000 |
| Warranty Time UOM | MO |
| Warranty Time | 12 |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 9027102000 |
| UPC | 00689604145548 |
| VMRS Code | 045021011 |
| UNSPSC | 41111924 |
DELPHI ES20009 Cross References
| Brand | Part Number |
|---|---|
| ACDelco | 2131162, 2134116, 2134299, 2134693 |
| Airtex | 5S10180, 5S4404, 5S8184 |
| BorgWarner | OS1689 |
| Bosch | 15114, 15283 |
| DENSO | 234-4332, 234-4673, 234-4563 |
| DENSO Auto Parts | 234-4563, 234-4673 |
| General Motors | 12572707, 12607145, 12616502, 12622308 |
| N/A | 2344673, 12617648, 25024698 |
| NTK | 21555 |
| Oextra | REA1578 |
| SPECTRA PREMIUM | OS5472 |
| Saab | 12 61 7648 |
| Standard Motor Products | SG935 |
| Walker Products | 25024492 |
| Wells | SU11633, SU1517, SU9650 |
DELPHI ES20009 Fits Vehicles
- GMC Sierra 3500 Classic (2007)
- GMC Sierra 2500 HD Classic (2007)
- Chevrolet Silverado 3500 Classic (2007)
- Chevrolet Silverado 2500 HD Classic (2007)
- Chevrolet Impala (2014)
- Buick Verano (2012-2017)
- GMC Sierra 3500 HD (2011-2015)
- Chevrolet Silverado 3500 HD (2011-2015)
- Buick Regal (2011-2017)
- Buick LaCrosse (2010-2016)
- Saturn Aura (2009)
- Pontiac G6 (2009-2010)
- Chevrolet Malibu (2008-2014)
- Cadillac STS (2007-2010)
- Cadillac SRX (2007-2009)
- GMC Yukon XL 2500 (2003-2006)
- GMC Sierra 3500 (2003-2006)
- GMC Sierra 2500 HD (2003-2006, 2011-2015)
- Chevrolet Suburban 2500 (2003-2006)
- Chevrolet Silverado 3500 (2003-2006)
- Chevrolet Silverado 2500 HD (2003-2006, 2011-2015)
- Chevrolet Avalanche 2500 (2003-2006)
