(888) 312-8812 Login SignupDELPHI ES10649 Oxygen Sensor
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
DELPHI ES10649 Part Description
DELPHI ES10649 Specifications
Product Attributes
| Package Contents | Oxygen Sensor, Instruction Sheet |
| Position(s) | Front, Left, Rear, Right. For the position specific to your vehicle, refer to the Applications. |
| Wiring Harness Length | 20.9 IN |
| Wiring Harness Length | 530.0 MM |
| Sensor Type | Heated |
| Terminal Type | Blade |
| Universal Or Specific Fit | Specific |
| Band Type | Narrow |
| Wire Quantity | 4 |
| Grade Type | Regular |
| Connector Shape | Square |
| Terminal Quantity | 4 |
| Connector Gender | Male |
| Terminal Gender | Male |
| Thread Diameter | 0.7 IN |
| Thread Diameter | 18.0 MM |
| Wrench Size | 22mm |
| Thread Size | M18x1.5 |
| Overall Length | 22.0 IN |
| Overall Length | 560.0 MM |
| Mounting Type | Threaded |
| Wire Gauge Measurement | 20.0 GU |
Additional Information
| Warranty Distance UOM | DH |
| Warranty Distance | 12000 |
| Harmonized Tariff Code (Schedule B) | 9027100000 |
| Warranty Time UOM | MO |
| Warranty Time | 12 |
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (HTS) | 9027102000 |
| UPC | 00689604117989 |
| VMRS Code | 045021011 |
| UNSPSC | 41111924 |
DELPHI ES10649 Cross References
| Brand | Part Number |
|---|---|
| ACDelco | 2131357, 2131432, 2131434, 2131438, 2131461, 2131462, 2131466 |
| Beck/Arnley | 156-4380, 156-4384 |
| BorgWarner | OS1438, OS934, OS945 |
| Bosch | 13081, 13448 |
| DENSO | 234-4511, 234-4520, 234 4511 |
| DENSO Auto Parts | 234-4511, 234-4520 |
| Kem | 138-517, 138-773 |
| N/A | 138517, 138773, 1564380, 1564384, 8946535190, 8946539515, 8946560051, 8946560110, 8946569065, 8946569075, 8946569115, 8946569125, 2344511 |
| NTK | 24044, 24080 |
| Oextra | REA1438, REA1473 |
| Standard Motor Products | SG379, SG559, SG685 |
| Toyota | 89465-35190, 89465-39515, 89465-60051, 89465-60110, 89465-69065, 89465-69075, 89465-69115, 89465-69125 |
| Walker Products | 25024501 |
| Wells | SU4913, SU4957, SU4958 |
DELPHI ES10649 Fits Vehicles
- Toyota Pickup (1992-1993)
- Toyota Land Cruiser (1993-1995)
