(888) 312-8812 Login SignupDELPHI HP10203 Fuel Pump Hanger Assembly
SHIPS MONDAY
$20499
Limited availability at this price!
In Stock
Get it by Thursday, Feb 12
DELPHI HP10203 Part Description
Manufacturer
Product Description
Fuel Pump Hanger Assembly
Features & Benefits
- Delphi is a global OE manufacturer and all fuel pumps are built to Delphi's OE standards
- Delphi pumps are designed to operate under extreme temperatures with quick engine starts
- Metal tubes in Delphi hangers are routed so as to not contact the tank at any point eliminating noise and vibration during vehicle operation
- Empty float height and float retention matches OE specifications and guarantees correct gas gauge reading
- Restores fast pressure performance and system integrity, translating to better pumping through less energy
- Lower failure rates due to its innovative design and durability
- Part is validated, tested and matched to the right vehicle application
- Lower amperage draws less load on vehicle's electrical system
- Always be sure to check and clean fuel tank to avoid unnecessary returns
DELPHI HP10203 Specifications
Product Attributes
| Item Grade | Standard Replacement |
| Fuel Level Sender Assembly Included | No |
| System Pressure | 36 psi |
| Package Contents | Fuel Pump Hanger Assembly w/o Float Arm, Instruction Sheet |
| Outlet Outside Diameter | 0.313 IN |
| Voltage | 12.0 2H |
| Fuel Type | Gas |
| Maximum Pressure | 94.0 PS |
| Terminal Type | Pin |
| Gasket Or Seal Included | Yes |
| Terminal Quantity | 2 |
| Terminal Gender | Male |
| Strainer Included | Yes |
| Inlet Type | Strainer |
| Outlet Type | Hose |
| Outlet Quantity | 2 |
| In Tank or External | In Tank |
| Internal Or External Strainer | External |
| Pump Type | Electric |
| Average Current Draw | 6.0 68 |
| Average Flow Rating | 26.0 GPH |
| Material | Metal |
| Fuel Sending Unit Included | No |
| Negative Ground | No |
| Mounting Hardware Included | No |
| Grade Type | Premium |
| Connector Shape | Rectangle |
| Lock Ring Included | No |
| Connector Gender | Female |
| Inlet Quantity | 1 |
| Fuel Pump Included | Yes |
| Gasket Or Seal Material | Nitrile Rubber |
| Minimum Pressure | 36 PS |
| Pump Design | Turbine |
| Fuel Tank Pressure Sensor Included | No |
| Universal Or Specific Fit | Specific |
Additional Information
| Harmonized Tariff Code (HTS) | 8413309030 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Country of Origin (Primary) | MX |
| Harmonized Tariff Code (Schedule B) | 8413309000 |
| UPC | 00689604233597 |
| VMRS Code | 044003257 |
| UNSPSC | 40151532 |
DELPHI HP10203 Cross References
| Brand | Part Number |
|---|---|
| AUTOBEST | F4333A |
| Airtex | E8023, E8322H |
| AutoZone | DHP10203 |
| Bosch | 67830, 69407, 69624 |
| Carter | P72090, P72227 |
| DENSO Auto Parts | 950-0185, 951-0010 |
| EVO Driveline | AFS0327P, RE0327P |
| GMB | 535-6020 |
| Honda | 17040-SM4-A30, 17708-SM4-A32 |
| Import Direct | E16024 |
| N/A | 17040SM4A30, 17708SM4A32, USEP8322H, A25549, 4010014 |
| Precision Fuel | A30194 |
| Spectra Premium | SP1129, SP8322H |
DELPHI HP10203 Fits Vehicles
- Honda Accord (1990-1993)
