(888) 312-8812 Login SignupDELPHI FG1221 Fuel Pump Module Assembly
$19949
Limited availability at this price!
In Stock
Get it by Thursday, Feb 26
DELPHI FG1221 Part Description
Manufacturer
Product Description
Fuel Pump Module Assembly
Features & Benefits
- Delphi is a global OE manufacturer and all fuel pumps are built to Delphi's OE standards
- Empty float height and float retention matches OE specifications and guarantees correct gas gauge reading
- Lower amperage draws less load on vehicle's electrical system
- Part is validated, tested and matched to the right vehicle application
- Always be sure to check and clean fuel tank to avoid unnecessary returns
- Lower failure rates due to its innovative design and durability
DELPHI FG1221 Specifications
Product Attributes
| Fuel Level Sender Assembly Included | Yes |
| Package Contents | Fuel Pump Module Assembly w/Float Arm, Instruction Sheet |
| Item Grade | Standard Replacement |
| System Pressure | 44 psi |
| Vapor Pressure Sensor | No |
| Outlet Outside Diameter | 0.375 IN |
| Voltage | 12 2H |
| Fuel Type | Gas |
| Regulator Included | Yes |
| Maximum Pressure | 51 PS |
| Terminal Type | Blade |
| Gasket Or Seal Included | Yes |
| Terminal Quantity | 4 |
| Lock Ring Included | No |
| Terminal Gender | Male |
| Strainer Included | Yes |
| Inlet Type | Strainer |
| Outlet Type | Quick Connect |
| Outlet Quantity | 1 |
| In Tank or External | In Tank |
| Resistance Ohms Empty | 325 82 |
| Resistance Ohms Full | 18 82 |
| Internal Or External Strainer | External |
| Pump Type | Electric |
| Average Current Draw | 6 68 |
| Average Flow Rating | 45 GPH |
| Fuel Sending Unit Included | Yes |
| Negative Ground | No |
| Mounting Hardware Included | No |
| Grade Type | Premium |
| Connector Quantity | 1 |
| Connector Shape | Rectangle |
| Housing Material | Plastic |
| Installation Warnings | No |
| Connector Gender | Female |
| Fuel Filter Included | Yes |
| Gasket Or Seal Material | Nitrile Rubber |
| Minimum Pressure | 44 PS |
| Wire Harness Included | No |
| Pump Design | Turbine |
| Fuel Tank Pressure Sensor Included | No |
| Universal Or Specific Fit | Specific |
Additional Information
| Harmonized Tariff Code (HTS) | 8413309030 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Harmonized Tariff Code (Schedule B) | 8413309000 |
| Country of Origin (Primary) | TH |
| UPC | 00689604231913 |
| VMRS Code | 044003258 |
| UNSPSC | 25172409 |
DELPHI FG1221 Cross References
| Brand | Part Number |
|---|---|
| AUTOBEST | F3167A |
| Airtex | E7154, E7156MN |
| AutoZone | DFG1221 |
| Bosch | 67726, 69316 |
| CARTER FUEL PUMPS | P76520M |
| Carter | P76224, P76520M |
| Chrysler | RL093788AB, 5093 788AA, RL093788AC |
| DENSO Auto Parts | 950-0199 |
| GMB | 520-2015 |
| N/A | 5093788AA, USEP7156M, C0459M, 4010371 |
| Precision Fuel | A30180, E16022 |
| Spectra Premium | SP1132, SP7156M |
DELPHI FG1221 Fits Vehicles
- Jeep Wrangler (2003-2004)
