(888) 312-8812 Login SignupDELPHI FG1169 Fuel Pump Module Assembly
MSRP: $612.48
$61149
Save $0.99
Limited availability at this price!
In Stock
Get it by Wednesday, Mar 11
DELPHI FG1169 Part Description
Manufacturer
Product Description
Fuel Pump Module Assembly
Features & Benefits
- Delphi is a global OE manufacturer and all fuel pumps are built to Delphi's OE standards
- Empty float height and float retention matches OE specifications and guarantees correct gas gauge reading
- Lower amperage draws less load on vehicle's electrical system
- Part is validated, tested and matched to the right vehicle application
- Always be sure to check and clean fuel tank to avoid unnecessary returns
- Lower failure rates due to its innovative design and durability
DELPHI FG1169 Specifications
Product Attributes
| Item Grade | Standard Replacement |
| Fuel Level Sender Assembly Included | Yes |
| Package Contents | Fuel Pump Module Assembly w/Float Arm, Instruction Sheet |
| Vapor Pressure Sensor | No |
| System Pressure | 44 psi |
| Outlet Outside Diameter | 0.313 IN |
| Voltage | 12 2H |
| Fuel Type | Gas |
| Regulator Included | Yes |
| Maximum Pressure | 94 PS |
| Terminal Type | Pin |
| Gasket Or Seal Included | Yes |
| Terminal Quantity | 4 |
| Lock Ring Included | No |
| Terminal Gender | Male |
| Strainer Included | Yes |
| Inlet Type | Strainer |
| Outlet Type | Quick Connect |
| Outlet Quantity | 1 |
| In Tank or External | In Tank |
| Resistance Ohms Empty | 410 82 |
| Resistance Ohms Full | 15 82 |
| Internal Or External Strainer | Internal |
| Pump Type | Electric |
| Average Current Draw | 7 68 |
| Average Flow Rating | 17 GPH |
| Fuel Sending Unit Included | Yes |
| Negative Ground | No |
| Mounting Hardware Included | No |
| Grade Type | Premium |
| Connector Quantity | 1 |
| Connector Shape | Trapezoid |
| Housing Material | Plastic |
| Installation Warnings | No |
| Connector Gender | Female |
| Fuel Filter Included | Yes |
| Gasket Or Seal Material | Nitrile Rubber |
| Minimum Pressure | 44 PS |
| Wire Harness Included | No |
| Pump Design | Turbine |
| Fuel Tank Pressure Sensor Included | No |
| Universal Or Specific Fit | Specific |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8413309000 |
| Country of Origin (Primary) | TH |
| Harmonized Tariff Code (HTS) | 8413309030 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| UPC | 00689604231456 |
| VMRS Code | 044003258 |
| UNSPSC | 25172409 |
DELPHI FG1169 Cross References
| Brand | Part Number |
|---|---|
| Airtex | E8722M, E8727 |
| AutoZone | DFG1169 |
| Bosch | 69932 |
| Carter | P72189, P76820M |
| DENSO Auto Parts | 950-0205 |
| GMB | 570-2130 |
| Import Direct | A30457 |
| N/A | 7702006120, 7702006121, USEP8722M, C0659M, 4010647 |
| Spectra Premium | SP9043M |
| Toyota | 77020-06120, 77020-06121 |
| URO | TY0517357 |
DELPHI FG1169 Fits Vehicles
- Toyota Solara (2007-2008)
- Toyota Camry (2007-2011)
DELPHI FG1169 Customer Reviews
No reviews yet
Be the first to review this product!
DELPHI FG1169 Questions & Answers
No questions yet
Be the first to ask a question about this product!
