(888) 312-8812 Login SignupDELPHI FG0280 Fuel Pump Module Assembly
$18499
Limited availability at this price!
1 Day Lead Time
Get it by Thursday, Mar 5
DELPHI FG0280 Part Description
Manufacturer
Product Description
Fuel Pump Module Assembly
Features & Benefits
- Delphi is a global OE manufacturer and all fuel pumps are built to Delphi's OE standards
- Empty float height and float retention matches OE specifications and guarantees correct gas gauge reading
- Lower amperage draws less load on vehicle's electrical system
- Part is validated, tested and matched to the right vehicle application
- Always be sure to check and clean fuel tank to avoid unnecessary returns
- Lower failure rates due to its innovative design and durability
DELPHI FG0280 Specifications
Product Attributes
| Item Grade | Standard Replacement |
| Package Contents | Fuel Pump Module Assembly w/Float Arm, Seal, Instruction Sheet |
| Fuel Level Sender Assembly Included | Yes |
| System Pressure | 51 psi |
| Vapor Pressure Sensor | No |
| Outlet Outside Diameter | 0.375 IN |
| Voltage | 12 2H |
| Fuel Type | Gas |
| Regulator Included | Yes |
| Maximum Pressure | 53 PS |
| Terminal Type | Blade |
| Gasket Or Seal Included | Yes |
| Terminal Quantity | 4 |
| Lock Ring Included | No |
| Terminal Gender | Male |
| Strainer Included | Yes |
| Inlet Type | Strainer |
| Outlet Type | Quick Connect |
| Outlet Quantity | 1 |
| In Tank or External | In Tank |
| Resistance Ohms Empty | 70 82 |
| Resistance Ohms Full | 1050 82 |
| Internal Or External Strainer | External |
| Pump Type | Electric |
| Average Current Draw | 9 68 |
| Average Flow Rating | 26 GPH |
| Fuel Sending Unit Included | Yes |
| Negative Ground | No |
| Mounting Hardware Included | No |
| Grade Type | Premium |
| Connector Quantity | 1 |
| Connector Shape | Oval |
| Housing Material | Plastic |
| Installation Warnings | No |
| Connector Gender | Female |
| Fuel Filter Included | Yes |
| Gasket Or Seal Material | Nitrile Rubber |
| Minimum Pressure | 51 PS |
| Wire Harness Included | No |
| Pump Design | Turbine |
| Fuel Tank Pressure Sensor Included | No |
| Universal Or Specific Fit | Specific |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8413309000 |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8413309030 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| UPC | 00689604076262 |
| VMRS Code | 044003258 |
| UNSPSC | 25172409 |
DELPHI FG0280 Cross References
| Brand | Part Number |
|---|---|
| ACDelco | MU2056 |
| AUTOBEST | F3141A |
| Airtex | E7130M |
| AutoZone | DFG0280 |
| Bosch | 67678, 67686, 67700 |
| CARTER FUEL PUMPS | P74824M |
| Carter | P74824M |
| Chrysler | 5014 351AA, 5014 351AB, 5014 351AC |
| DENSO | 953-3031 |
| DENSO Auto Parts | 953-3030, 953-3031 |
| EVO Driveline | AFS0804S, RE0763S, RE0804S, AFS0763S |
| GMB | 520-2520 |
| N/A | 89032326, 9533030, 9533031, 5014351AA, 5014351AB, 5018691AA, 5018691AB, 5018696AA, 5278117AB, RL018691AB, USEP7130M, C0447M, 4010241 |
| Precision Fuel | A27036 |
| Spectra Premium | SP7141M, SP7130M |
DELPHI FG0280 Fits Vehicles
- Chrysler Neon (2000)
- Plymouth Neon (2000)
- Dodge Neon (2000)
