(888) 312-8812 Login SignupDELPHI FG0203 Fuel Pump Module Assembly
MSRP: $270.14
$20799
Save $62.15
Limited availability at this price!
In Stock
Get it by Thursday, Feb 26
DELPHI FG0203 Part Description
Manufacturer
Product Description
Fuel Pump Module Assembly
Features & Benefits
- Delphi is a global OE manufacturer and all fuel pumps are built to Delphi's OE standards
- Empty float height and float retention matches OE specifications and guarantees correct gas gauge reading
- Lower amperage draws less load on vehicle's electrical system
- Part is validated, tested and matched to the right vehicle application
- Always be sure to check and clean fuel tank to avoid unnecessary returns
- Lower failure rates due to its innovative design and durability
DELPHI FG0203 Specifications
Product Attributes
| System Pressure | 58 psi |
| Vapor Pressure Sensor | No |
| Item Grade | Standard Replacement |
| Package Contents | Fuel Pump Module Assembly w/Float Arm, Seal, Instruction Sheet |
| Fuel Level Sender Assembly Included | Yes |
| Outlet Outside Diameter | 0.375 IN |
| Voltage | 12 2H |
| Fuel Type | Gas |
| Regulator Included | Yes |
| Maximum Pressure | 65 PS |
| Terminal Type | Pin |
| Gasket Or Seal Included | Yes |
| Terminal Quantity | 4 |
| Lock Ring Included | No |
| Terminal Gender | Female |
| Strainer Included | Yes |
| Inlet Type | Strainer |
| Outlet Type | Quick Connect |
| Outlet Quantity | 2 |
| In Tank or External | In Tank |
| Resistance Ohms Empty | 1053 82 |
| Resistance Ohms Full | 60 82 |
| Internal Or External Strainer | External |
| Pump Type | Electric |
| Average Current Draw | 4 68 |
| Average Flow Rating | 18 GPH |
| Fuel Sending Unit Included | Yes |
| Negative Ground | No |
| Mounting Hardware Included | No |
| Grade Type | Premium |
| Connector Quantity | 1 |
| Connector Shape | Rectangle |
| Housing Material | Plastic |
| Installation Warnings | No |
| Connector Gender | Male |
| Fuel Filter Included | No |
| Gasket Or Seal Material | Nitrile Rubber |
| Minimum Pressure | 58 PS |
| Wire Harness Included | No |
| Pump Design | G-Rotor |
| Fuel Tank Pressure Sensor Included | No |
| Universal Or Specific Fit | Specific |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8413309000 |
| Country of Origin (Primary) | TH |
| Harmonized Tariff Code (HTS) | 8413309030 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| UPC | 00689604061404 |
| VMRS Code | 044003258 |
| UNSPSC | 25172409 |
DELPHI FG0203 Cross References
| Brand | Part Number |
|---|---|
| ACDelco | MU2040, MU43 |
| AUTOBEST | F3090A |
| Airtex | E7089M |
| AutoZone | EFG0203 |
| BorgWarner | P249M |
| Bosch | 67639 |
| CARTER FUEL PUMPS | P74693M |
| Carter | P74693M |
| Chrysler | 4764184, 4798947, 4778 198, 4897 420AA, 4897 420AB |
| DENSO | 953-3010 |
| DENSO Auto Parts | 951-0007, 953-3010 |
| DORMAN | 2630344 |
| EVO Driveline | AFS0301S, RE0301S |
| GMB | 520-2100 |
| General Motors | 25167028 |
| Kem | EFP7089M |
| N/A | 9510007, 9533010, 4778198, 4897420AA, 4897420AB, USEP7089M, C0421M, 4010064 |
| Precision Fuel | A30050 |
| Spectra Premium | SP6043M, SP7003H |
DELPHI FG0203 Fits Vehicles
- Plymouth Breeze (1996-1997)
- Dodge Stratus (1995-1997)
- Chrysler Sebring (1996-1998)
- Chrysler Cirrus (1995-1997)
