CENTRIC 103.13940 Part Description
Manufacturer
Product Description
C-Tek Ceramic Brake Pads with Shims
Features & Benefits
- Shimmed to eliminate noise and vibration. Formulated for reduced noise. Advanced Ceramic compounds. Post cured for consistent performance throughout the service life of the brake pad. 100% Asbestos free. Scorched for easy bed-in.
- Vibration Damping Shims
- For optimal noise control over a wide temperature range
- OE Matched Slots and Chamfers
- Slots & chamfers match OE design, allowing for less noise, vibration, and harshness.
CENTRIC 103.13940 Specifications
Product Attributes
| Notes01 [cntrc] | 2 Pads with 1 Wear Sensor |
| Hardware Kit Number [cntrc] | 117.40051 |
| Weight [cntrc] Kgs | 1.5855 |
| Weight [cntrc] Lbs | 3.5 |
| Product Grade [cntrc] | Standard |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Notes02 [cntrc] | Drilled for Spreader Springs |
| Pad Wear Sensor Included | Yes |
| Friction Material Composition | Ceramic |
| Mounting Hardware Included | No |
| Pad Shims Included | Yes |
| Friction Material Attachment | Integrally Molded |
| Pad Quantity | 4 |
| Prepared For Pad Wear Sensor | Yes |
| Outer Pad Height | 56.3 MM |
| Outer Pad Height | 2.216 IN |
| Inner Pad Height | 56.3 MM |
| Inner Pad Height | 2.216 in |
| Outer Pad Width | 5.370 IN |
| Outer Pad Width | 136.400 MM |
| Inner Pad Width | 136.400 MM |
| Inner Pad Width | 5.370 in |
| Outer Pad Overall Thickness | 16.000 MM |
| Outer Pad Overall Thickness | 0.626 in |
| Inner Pad Overall Thickness | 16.000 MM |
| Inner Pad Overall Thickness | 0.626 IN |
| Pad Shim Attachment Type | Tabbed |
| Pad Shims Attached | Yes |
| Pad Wear Sensor Attached | Yes |
| Car Position [cntrc] | Rear |
| Friction Material Slot Type | Straight |
| 103.13940 | D1394-8502 |
| Slotted | Yes |
| Pad Wear Sensor Type | Mechanical |
| Chamfered Edges | Yes |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305040 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | IN |
| Original Equipment Manufacturer | Volkswagen |
| OEM's Part Number | 1EA698151B |
| Canadian Harmonizing Tariff Code | 8708301900 |
| UPC | 00805890892656 |
CENTRIC 103.13940 Cross References
CENTRIC 103.13940 Fits Vehicles
- Honda CR-Z (2011-2015)
- Honda Fit (2009-2013, 2015-2020)
