"OE Solutions" Fuel Pump Module
Cadillac DeVille 1999-98, Cadillac Eldorado 2002-98
Fuel, Pump, Module, Assembly, Fuels, Pumps, Modules, Assemblies
| Inlet Outside Diameter | 7.89 MM |
| Length | 19.5 MM |
| Housing Width | 94 MM |
| Wire Gauge Measurement | 1.5 GU |
| Connector Color | White |
| Width | 6.35 MM |
| Maximum Pressure | 116.03 PS |
| Terminal Type | Spade |
| Height | 207 MM |
| Universal Or Specific Fit | Specific |
| Housing Length | 174 MM |
| Wire Quantity | 4 |
| Connector Shape | Flat Plug |
| Gasket Or Seal Included | Yes |
| Housing Material | Plastic |
| Terminal Quantity | 4 |
| Top Mount Diameter | 6.35 MM |
| Lock Ring Included | No |
| Connector Gender | Female |
| Terminal Gender | Male Female |
| Maximum Flow Rating | 25.63 GPH |
| Inlet Type | Male |
| Outlet Type | Male |
| Outlet Quantity | 1 |
| Outlet Diameter | 9.49 mm |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (Schedule B) | 8413309000 |
| UPC | 00747214154470 |
| VMRS Code | 044003258 |
| UNSPSC | 39121552 |
