(888) 312-8812 Login SignupRAYBESTOS 980601R Raybestos R-Line Brake Rotor
MSRP: $107.66
$7649
Save $31.17
Limited availability at this price!
In Stock
Get it by Wednesday, Mar 11
RAYBESTOS 980601R Part Description
Manufacturer
Product Description
Raybestos R-Line Brake Rotor
Application Summary
2019-2013 Ford Escape Front, 2017-2013 Ford C-Max Front, 2011-2004 Volvo S40 Front, 2012-2006 Volvo C70 Front, 2013-2007 Volvo C30 Front, 2011-2005 Volvo V50 Front
Features & Benefits
- OE Fit, Form, and Function
- Developed from OE samples and made with G3000-qualified material, ensuring OE fit, form and function for dependable braking.
- SAE Standard
- R-Line Rotors meet the SAE standard for tensile strength, providing structural integrity and a maximum service life.
- Low Initial Lateral Runout and Thickness Variation
- R-Line Rotors have a small parameter lateral runout and a thickness variation ensuring less pedal pulsation, less brake noise, and an extended pad life.
- Mill Balanced Edges
- R-Line Rotors are mill balanced and 100 percent validated. This helps minimize the thickness variation on the rotor and leads to minimized vibration and smoother stopping.
RAYBESTOS 980601R Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.504 IN |
| Center Hole Diameter | 63.6 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Discard Thickness | 0.91 IN |
| Discard Thickness | 23.1 MM |
| Harmonize Code | 8708.30.5030 |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 4.25 IN |
| Mounting Bolt Hole Circle Diameter | 107.95 MM |
| Mounting Bolt Hole Diameter | 0.54 IN |
| Mounting Bolt Hole Diameter | 13.7 MM |
| Nominal Thickness | 0.98 IN |
| Nominal Thickness | 24.9 MM |
| Outside Diameter | 11.811 IN |
| Outside Diameter | 300 MM |
| Overall Height | 1.917 IN |
| Overall Height | 48.7 MM |
| Salability Restrictions | No |
| Stud/Lug Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00887213005325 |
RAYBESTOS 980601R Cross References
RAYBESTOS 980601R Fits Vehicles
- Volvo C30 (2007-2013)
- Volvo C70 (2006-2013)
- Volvo V50 (2005-2011)
- Volvo S40 (2004-2012)
- Ford C-Max (2013-2017)
- Ford Escape (2013-2019)
