FRAM CH10759 Part Description
Manufacturer
Product Description
FRAM, CH10759, Oil Filter
Features & Benefits
- Proven protection for up to 10,000 miles (16,000 kilometers)
- Engineered for use with synthetic or conventional motor oils
- Filter media is a blend of fiber and resin that captures 95% of the dirt particles
- The perfect balance of dirt-trapping efficiency and dirt-holding capacity
- Includes gaskets and O-rings manufactured to endure the high pressures and high temperatures in today’s engines
- Includes gaskets and O-rings manufactured to endure the high pressures and high temperatures in today's engines
Cartridge Oil Filter
FRAM CH10759 Specifications
Product Attributes
| Filter Media Material | Cellulose/Synthetic Blend |
| Height | 3.979 IN |
| Grade Type | Regular |
| Filter Type | Cartridge |
| Non Slip Grip | No |
| Anti-Drain Back Valve | No |
| Bypass Relief Valve | No |
| Grade | Advanced |
| Housing Color | NA |
| Inside Diameter Bottom | 0.867 IN |
| Meets Or Exceeds Original Equipment Manufacturer Specifications | Yes |
| New Or Remanufactured | New |
| O-ring (1) Inside Diameter | 0.552 IN |
| O-ring (1) Outside Diameter | 0.670 IN |
| O-ring (1) Thickness | 0.118 IN |
| O-ring (2) Inside Diameter | 0.394 IN |
| O-ring (2) Outside Diameter | 0.512 IN |
| O-ring (2) Thickness | 0.118 IN |
| O-ring Inside Diameter | 2.896 IN |
| O-ring Outside Diameter | 3.034 IN |
| O-ring Thickness | 0.138 IN |
| O-Rings Included | Yes |
| Outer Diameter Bottom | 2.620 in |
| Outer Diameter Top | 2.620 in |
| Replacable Filter | Yes |
| Reusable | No |
| Top Inside Diameter | 0.867 in |
| Torque Nut | No |
| Washable | No |
| Bottom Inside Diameter | 0.867 IN |
| Outside Diameter Top | 2.620 in |
| Replaceable Filter | Yes |
Additional Information
| Country of Origin (Primary) | AR |
| Harmonized Tariff Code (HTS) | 8421230000 |
| Warranty Special | See Rep |
| Warranty Special UOM | SR |
| Warranty Time | 30 |
| Warranty Time UOM | DA |
| UPC | 00009100550200 |
| UNSPSC | 15121501 |
FRAM CH10759 Cross References
| Brand | Part Number |
|---|---|
| BALDWIN | P40024 |
| Carquest | 84262 |
| Carquest Premium Filters | 84262 |
| Champ | P995 |
| Champion | COC10759 |
| Champion Filters | COC10759 |
| ECOGUARD | X10231 |
| FVP | G7262 |
| Factory Motor Parts | G7262 |
| Hastings | LF674 |
| LUBER-FINER | P995 |
| MAHLE | OX 388D ECO, OX388D, OX388DECO, OX 388D, OX 388 D |
| MANN-HUMMEL FILTERS | HU7008Z |
| Mann-Filter | HU7008Z |
| MicroGard | MGL57262 |
| NAPA | 7262 |
| PREMIUM GUARD | PG6288EX |
| Parts Master | 67262 |
| Premium Guard | PG6288, POF6287 |
| PureZone | 8-57262 |
| Purolator | L26288 |
| STP Filters | S10759, S10759XL |
| Valvoline | VO-132 |
| Volkswagen | 03L 115 466, 03L 115 562 |
| WIX FILTERS | 57262 |
| Wega | WOE680 |
| Wix | 57262 |
FRAM CH10759 Fits Vehicles
- Suzuki Aerio (2002)
- Volkswagen Amarok (2011-2013)
- Volkswagen Passat (2012-2014)
