AUTOLITE XS3922 Part Description
Manufacturer
Product Description
Autolite XS3922 Xtreme Sport Iridium Powersports Spark Plug
Features & Benefits
- Design to withstand the extreme operating temperatures experienced during a power sports engine's combustion.
- Engineered with an iridium-enhanced fine-wire center electrode that delivers greater ignitability over standard non-fine-wire spark plug.
- 0.6mm finewire design with Sport V-trim ground electrode for more horsepower than standard plug
- The tapered ground electrode provides improved ignitability for more efficient and smoother starts.
- Up to 26% quicker engine starts than a standard non-finewire spark plug* (* Testing performed by independent lab)
- Its high alumina multi-rib ceramic insulator provides thermal conductivity and superior insulation for increased strength.
- Focused ignition prevents fouling better than leading standard plug for reliable starting in any season or weather
AUTOLITE XS3922 Specifications
Product Attributes
| Resistance | 4000 82 |
| Ground Electrode Tip Design | Taper Cut |
| Ground Electrode Core Material | Nickel |
| Electrical Terminal Type | Non-Removable Nut |
| Center Electrode Core Material | Copper |
| Center Electrode Tip Material | Iridium |
| Pre-Gap Size | 0.044 IN |
| Ground Electrode Quantity | 1 |
| Hex Size | 16 MM |
| Seat Type | Flat |
| Reach | 0.75 IN |
| Thread Diameter | 14 MM |
| Insulator Material | Ceramic |
| Resistor Type | Yes |
| Ground Electrode Tip Material | Nickel |
| Center Electrode Design | Fine Wire |
| Center Electrode Projection | Mid Projection |
| Washer(s) Included | Yes |
| Grade Type | Performance |
| Hex Size | 5/8 IN |
| Manufacturer Heat Range | 11 |
| Skirt | Yes |
| Hex Type | Hex |
| Indexed | No |
| Reach | 19.049999999999997 MM |
| Pre-Gap Size | 1.1176 MM |
| Thread Type Standard | Metric |
| Insulator Height | 50.8 MM |
| Thread Size | M14 - 1.25 |
| Center Electrode Insulator Tip Projection | 0.133 IN |
| Washer Type | Crush |
| Thread Diameter | 14 MM |
| Center Electrode Insulator Tip Projection | 3.4 MM |
| Insulator Height | 1.999 IN |
Additional Information
| Country of Origin (Primary) | MX |
| Harmonized Tariff Code (Schedule B) | 8511100000 |
| Warranty Special | No Warranty |
| Warranty Special UOM | TX |
| Harmonized Tariff Code (HTS) | 8511100000 |
| UPC | 00009100262813 |
| UNSPSC | 26101732 |
AUTOLITE XS3922 Cross References
| Brand | Part Number |
|---|---|
| ACDelco | 41-829, FR1LS |
| BMW | 12 12 0 035 747, 12120035747 |
| Beck/Arnley | 176-5303 |
| Beru | 14 F-5 DU, 14 F-6 DPUR021, 14 F-6 DTU, 14 F-6 DUO, 14 FGH-6 DTUR, 14 FGR-7 CTU, 14 FR-5 DPUX, 14 FR-5 DTU, 14 FR-5 DU, 14 FR-6 DU, 14 FR-6 DUX, UXF 56 |
| Bosch | 7530 |
| Champion Spark Plug | 340, 3069, RC7PYCBX |
| DENSO Auto Parts | 3010, IK22, K22PR-L11, SK22PR-M11 |
| General Motors | 25171348 |
| Honda | PFR7G-11, PZFR7G-11, PFR7G11, PZFR7G11 |
| Motorcraft | AGSP12C |
| NGK | 1095, BCPR7EIX, BCPR7EIX-11, BKR7EIX, BKR7EIX-11, BKR8EIX, IFR7X7G, IFR8AG, IFR8H11 |
| NGK SPARK PLUGS | BCPR7EIX, 5690 |
| Ski-doo | 415129484, 415129950 |
| Splitfire - Archived | SF392B |
| Tata | 2820 1540 99 75 |
| Torch | K7RT3PP-11, K7RTC, K7RTP, K7RTPP-11, K7TC |
AUTOLITE XS3922 Fits Vehicles
- Polaris FS IQ WideTrak (2012-2013)
- Polaris WideTrak IQ (2009-2010)
- Ski-Doo Summit SP E-TEC 800R 174 (2017)
- Ski-Doo Summit X E-TEC 800R 174 (2017)
- Ski-Doo Summit Burton E-TEC 800R (2016-2017)
- Ski-Doo Summit X T3 Package E-TEC 800R 154 (2016)
- Ski-Doo Expedition Xtreme E-TEC 800R (2016-2017)
- Ski-Doo Summit SP T3 Package E-TEC 800R 174 (2016)
- Ski-Doo Summit SP T3 Package E-TEC 800R 163 (2016)
- Ski-Doo MX Z Blizzard E-TEC 800R (2016-2017)
- Ski-Doo Summit SP T3 Package E-TEC 800R 154 (2016)
- Ski-Doo Renegade Enduro E-TEC 800R (2016-2018)
- Ski-Doo Summit X T3 Package E-TEC 800R 174 (2015-2016)
- Polaris RZR 800 XC Edition (2014)
- Ski-Doo Renegade X-RS E-TEC 800R (2015-2017)
- Ski-Doo Summit X T3 Package E-TEC 800R 163 (2015-2016)
- Polaris RZR S 800 EPS LE (2014)
- Polaris RZR 4 800 EPS LE (2014)
- Polaris RZR S 800 (2014)
- Polaris RZR 800 (2014)
- Polaris Ranger 800 EPS Mid-Size LE (2014)
- Polaris RZR 800 EPS LE (2014)
- Polaris Ranger 800 EFI EPS LE (2013-2014)
- Polaris Ranger 800 EFI Mid-Size LE (2013)
- Polaris Ranger 800 EFI EPS (2013)
- Polaris Ranger RZR 4 800 EPS LE (2013)
- Polaris Ranger 800 EFI LE (2013)
- Polaris Ranger RZR S 800 EPS LE (2013)
- Polaris Ranger RZR 4 800 EPS Robby Gordon (2011)
- Polaris Ranger 800 EFI Mid-Size (2013-2014)
- Polaris Ranger 800 EFI (2013-2014)
- Ski-Doo Summit Freeride E-TEC 800R (2011)
- Polaris Turbo SwitchBack (2008-2009)
- Polaris Ranger RZR 800 S LE (2012-2013)
- Polaris Ranger RZR 4 800 EPS Robby Gordon LE (2012)
- Polaris Ranger 800 XP LE (2012)
- Polaris Ranger RZR 4 800 Gordon Edition (2010-2012)
- Polaris Ranger RZR 800 LE (2012-2013)
- Polaris Ranger RZR 4 800 (2012-2013)
- Polaris Ranger 800 XP EPS LE (2012)
- Polaris Ranger RZR 800 EPS LE (2012-2013)
- Polaris Ranger 800 Crew EPS LE (2012-2013)
- Ski-Doo Summit SP E-TEC 800R 163 (2012-2016)
- Ski-Doo Summit SP E-TEC 800R 146 (2012-2017)
- Ski-Doo Summit SP E-TEC 800R 154 (2012-2017)
- Ski-Doo Renegade X E-TEC 800R (2011-2016)
- Ski-Doo MX Z X-RS 800R (2010)
- Ski-Doo Renegade Backcountry X E-TEC 800R (2011-2017)
- Ski-Doo Renegade Backcountry E-TEC 800R (2011-2017)
- Ski-Doo Renegade Adrenaline E-TEC 800R (2011-2016)
- Ski-Doo MX Z X-RS E-TEC 800R (2012-2017)
- Ski-Doo MX Z X E-TEC 800R (2012-2016)
- Ski-Doo GSX SE E-TEC 800R (2012-2015)
- Ski-Doo MX Z TNT E-TEC 800R (2012-2016)
- Ski-Doo Freeride E-TEC 800R 137 (2012-2017)
- Ski-Doo Freeride E-TEC 800R 154 (2012-2017)
- Ski-Doo Freeride E-TEC 800R 146 (2012-2017)
- Polaris Sportsman Forest 800 6x6 (2012-2014)
- Polaris Sportsman 800 HO EFI Military (2008)
- Polaris Sportsman Forest 800 (2012-2014)
- Polaris Sportsman 800 6x6 Big Boss (2012-2014)
- Polaris Sportsman 700 MV (2006-2007)
- Ski-Doo Summit X E-TEC 800R 163 (2012-2015)
- Ski-Doo Summit X E-TEC 800R 146 (2012-2015)
- Ski-Doo Summit X E-TEC 800R 154 (2012-2015)
- Polaris Ranger 800 XP EPS (2012)
- Polaris Ranger 800 Crew EPS (2012)
- Polaris FS IQ Widetrack (2012-2013)
- Ski-Doo Summit Everest E-TEC 800R (2011)
- Polaris Turbo IQ (2011-2012)
- Polaris Turbo IQ LX (2011-2012)
- Polaris Ranger RZR 800 S (2009-2013)
- Polaris Ranger 800 HD EPS (2011-2012)
- Polaris Turbo IQ LXT (2011-2014)
- Polaris Ranger 800 Crew (2010-2014)
- Polaris Turbo LX (2010)
- Polaris Ranger RZR 800 EPS (2010-2011)
- Polaris Ranger 800 XP (2010-2012)
- Polaris Ranger 800 HD (2010)
- Polaris Ranger 6x6 800 (2010-2017)
- Polaris Wide Track IQ (2009-2010)
- Polaris Sportsman 800 EFI 6x6 Big Boss (2009-2011)
- Polaris IQ Turbo Dragon (2009-2010)
- Polaris Ranger HD 700 (2009)
- Honda MUV700 Big Red (2009-2013)
- Polaris Sportsman 700 EFI X2 (2008)
- Polaris Turbo Dragon (2008)
- Polaris Sportsman 800 EFI Touring (2008-2009)
- Polaris Ranger Crew 700 (2008)
- Polaris Sportsman 800 EFI HO (2008-2010)
- Polaris Ranger RZR 800 (2008-2013)
- Polaris IQ Turbo LX (2008)
- Polaris IQ Cruiser (2008)
- Honda TRX700XX (2008-2009)
- Polaris X2 800 EFI (2007)
- Polaris Sportsman 800 EFI Deluxe (2007)
- Polaris Sportsman 800 EFI X2 Deluxe (2007)
- Polaris Sportsman 800 EFI X2 (2007-2009)
- Polaris FST IQ Touring (2007-2010)
- Polaris FS IQ Touring (2007-2009)
- Polaris FST IQ LX (2007)
- Polaris FST IQ Cruiser (2007)
- Polaris FST IQ (2007)
- Polaris FST SwitchBack (2006-2007)
- Polaris Ranger 6x6 700 EFI (2006-2009)
- Polaris FS Touring (2006)
- Polaris FST Classic (2006)
- Polaris FST Touring (2006)
- Polaris FS Classic (2006)
- Honda TRX450ER Electric Start (2006-2009, 2012-2014)
- Polaris Sportsman MV7 (2005)
- Polaris Sportsman 800 EFI (2005-2014)
- Polaris Sportsman 700 EFI (2005-2007)
- Honda CRF450X (2005-2009, 2012, 2014-2017)
- Honda TRX450R (2004-2009)
- Polaris Frontier Touring (2003-2005)
- Polaris Sportsman 600 (2003-2005)
- Polaris Frontier Classic (2003-2004)
- Polaris Sportsman 700 (2002-2006)
- Honda CRF450R (2002-2008)
- Honda XR650R (2000-2007)
