(888) 312-8812 Login SignupNGK SPARK PLUGS GR5IX NGK Iridium IX Spark Plug
Tap to view 1 more
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
NGK SPARK PLUGS GR5IX Part Description
Manufacturer
Product Description
NGK Iridium IX Spark Plug
Features & Benefits
- SINGLE IRIDIUM TIP: Fine wire 0.6 millimeter iridium tip center electrode ensures high durability and a consistently stable spark
- IRIDIUM ALLOY CENTER ELECTRODE: Iridium's density (6x that of platinum) and extremely high melting point is perfect for modern high efficiency engines
- TAPERED CUT GROUND ELECTRODE: Reduced quenching design produces outstanding ignitability, improved acceleration, fuel efficiency and durability
- SOLID COPPER CORE: 98% pure copper core offers superior heat dissipation, conductivity and ultra wide heat ranges
- TRIVALENT METAL PLATING: Delivers superior anti-corrosion and anti-seizing properties, ensuring ease of installation and removal
- RECOMMENDED USAGE: Modified or high performance applications, or as an upgrade to OE nickel alloy spark plugs
NGK SPARK PLUGS GR5IX Specifications
Product Attributes
| Part Number | GR5IX |
| Stock Number | 7214 |
| Short Style Spark Plug | No |
| Service Number | GR5IX |
| Resistance | 5000.0 82 |
| Ground Electrode Tip Design | Taper Cut |
| Ground Configuration | J-Gap |
| Ground Electrode Core Material | Nickel |
| Washer(s) Included | Yes |
| Grade Type | Performance |
| Electrical Terminal Type | Non-Removable Nut |
| Center Electrode Core Material | Copper |
| Center Electrode Tip Material | Iridium |
| Pre-Gap Size | .040 IN |
| Ground Electrode Quantity | 1 |
| Hex Size | 13/16" |
| Insulator Height | 2.20 IN |
| Manufacturer Heat Range | 5 |
| Seat Type | Flat |
| Reach | 0.750 IN |
| Thread Diameter | 0.551 IN |
| Insulator Material | Ceramic |
| Resistor Type | Yes |
| Skirt Length | 0.0 IN |
| Ground Electrode Tip Material | Nickel |
| Skirt | No |
| Center Electrode Insulator Tip Projection | 0.14 IN |
| Center Electrode Design | Fine Wire |
| Washer Type | Crush |
| Center Electrode Projection | Mid Projection |
| Thread Size | M14 - 1.25 |
| Metallurgy | Single Iridium |
| Thread Type Standard | Metric |
| Pre-Gap Size | 1.0 MM |
| Insulator Height | 56.0 MM |
| Reach | 19.0 MM |
| 6648 | 0.0 MM |
| Center Electrode Insulator Tip Projection | 3.5 MM |
Additional Information
| Harmonized Tariff Code (HTS) | 8511100000 |
| Warranty Time UOM | MO |
| Warranty Time | 2 |
| Country of Origin (Primary) | JP |
| UPC | 00087295172148 |
| VMRS Code | 033003005 |
| UNSPSC | 26101732 |
NGK SPARK PLUGS GR5IX Cross References
NGK SPARK PLUGS GR5IX Fits Vehicles
- International MS1210 (1972-1974)
- International MHC1310 (1974)
- International M800 Post Office (1972)
- International M1200 (1972)
- International M1100 (1972)
- International 200 (1974)
- International 1310 (1972-1973)
- International 1210 (1972-1973)
- International 1110 (1972-1973)
- International 1010 (1972-1973)
- International 100 (1974)
- Pontiac Parisienne (1961)
- Plymouth Satellite (1965-1967)
- Plymouth Fury (1964-1966)
- Plymouth Cuda (1970-1971)
- Plymouth Belvedere (1966)
- GMC K35/K3500 Pickup (1968-1969)
- GMC K25/K2500 Suburban (1968)
- GMC K25/K2500 Pickup (1968-1969)
- GMC K15/K1500 Suburban (1968)
- GMC K15/K1500 Pickup (1968-1969)
- GMC C35/C3500 Pickup (1968-1969)
- GMC C25/C2500 Suburban (1968-1969)
- GMC C25/C2500 Pickup (1968-1969)
- GMC C15/C1500 Suburban (1968-1969)
- GMC C15/C1500 Pickup (1968-1969)
- Dodge Polara (1966)
- Dodge Coronet (1966-1971)
- Dodge Charger (1967)
- Chevrolet Nova (1970)
- Chevrolet Malibu (1966-1967)
- Chevrolet K30 Pickup (1968-1969)
- Chevrolet K20 Pickup (1968-1969)
- Chevrolet K10 Suburban (1968-1969)
- Chevrolet K10 Pickup (1968-1969)
- Chevrolet Impala (1961-1969)
- Chevrolet El Camino (1966-1970)
- Chevrolet Corvette (1966-1969)
- Chevrolet Chevy II (1968)
- Chevrolet Chevelle (1966-1969)
- Chevrolet Caprice (1966-1969)
- Chevrolet Camaro (1967-1969)
- Chevrolet C30 Pickup (1968-1969)
- Chevrolet C20 Suburban (1968-1969)
- Chevrolet C20 Pickup (1968-1969)
- Chevrolet C10 Suburban (1968-1969)
- Chevrolet C10 Pickup (1968-1969)
- Chevrolet Biscayne (1961-1969)
- Chevrolet Bel Air (1961-1969)
- Pontiac Sunburst (1985-1988)
- Pontiac Firefly (1985-1988)
- Ford Pinto (1971-1973, 1975-1976)
- Ford Mustang II (1974-1976)
- Ford Courier (1972-1979, 1981)
- Pontiac Sunbird (1986-1990, 1992-1994)
- Pontiac J2000 Sunbird (1984-1985)
- Pontiac J2000 (1982-1983)
- Pontiac Grand Am (1987-1989)
- Geo Spectrum (1989)
- GMC S15 (1982-1985)
- GMC S15 Jimmy (1983-1984)
- Chevrolet Sprint (1985-1988)
- Chevrolet Spectrum (1985-1988)
- Chevrolet S10 (1982-1985)
- Chevrolet S10 Blazer (1983-1984)
- Buick Skyhawk (1982-1987)
