(888) 312-8812 Login SignupNGK SPARK PLUGS CR8EB NGK Standard Spark Plug
Tap to view 2 more
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
NGK SPARK PLUGS CR8EB Part Description
Manufacturer
Product Description
NGK Standard Spark Plug
Features & Benefits
- ACTUAL OE or EQUIVALENT DESIGN: OEM quality construction nickel alloy center electrode provides consistent performance
- RECOMMENDED USAGE: Best for vehicles with OE nickel alloy plugs, not recommended on vehicles with factory precious metal plugs
- NGK's OE CERAMIC TECHNOLOGY: High grade alumina silicate ceramic creates a stronger insulator for optimal dielectric performance
- SOLID COPPER CORE: 98% pure copper core offers superior heat dissipation, conductivity and ultra wide heat ranges
- COLD-ROLLED THREADS: Prevents cross-threading and damage to cylinder heads
- TRIVALENT METAL PLATING: Delivers superior anti-corrosion and anti-seizing properties, ensuring ease of installation and removal
NGK SPARK PLUGS CR8EB Specifications
Product Attributes
| Part Number | CR8EB |
| Stock Number | 7784 |
| Short Style Spark Plug | No |
| Service Number | CR8EB |
| Resistance | 5000.0 82 |
| Ground Electrode Tip Design | Standard |
| Ground Configuration | J-Gap |
| Ground Electrode Core Material | Nickel |
| Washer(s) Included | Yes |
| Grade Type | Standard Replacement |
| Electrical Terminal Type | Non-Removable Nut |
| Center Electrode Core Material | Copper |
| Center Electrode Tip Material | Nickel |
| Pre-Gap Size | .032 IN |
| Ground Electrode Quantity | 1 |
| Hex Size | 5/8" (16mm) |
| Insulator Height | 2.00 IN |
| Manufacturer Heat Range | 8 |
| Seat Type | Flat |
| Reach | 0.750 IN |
| Thread Diameter | 0.394 IN |
| Insulator Material | Ceramic |
| Resistor Type | Yes |
| Skirt Length | 0.0 IN |
| Ground Electrode Tip Material | Nickel |
| Skirt | No |
| Center Electrode Insulator Tip Projection | 0.02 IN |
| Center Electrode Design | Standard |
| Washer Type | Crush |
| Center Electrode Projection | Non-Projected |
| Metallurgy | Copper |
| Thread Type Standard | Metric |
| Pre-Gap Size | 0.8 MM |
| Insulator Height | 50.8 MM |
| Reach | 19.0 MM |
| 6648 | 0.0 MM |
| Thread Size | M10 - 1.0 |
| Center Electrode Insulator Tip Projection | 0.5 MM |
Additional Information
| Warranty Time UOM | MO |
| Warranty Time | 2 |
| Country of Origin (Primary) | JP |
| Harmonized Tariff Code (HTS) | 8511100000 |
| UPC | 00087295177846 |
| VMRS Code | 033003005 |
| UNSPSC | 26101732 |
NGK SPARK PLUGS CR8EB Cross References
| Brand | Part Number |
|---|---|
| AUTOLITE | 4302, 4303 |
| Aprilia | 8570084 |
| Arctic Cat | 0217-813 |
| BMW | 12 12 7 653 439 |
| DENSO Auto Parts | U24ESR-NB |
| E3 SPARK PLUGS | E338 |
| Kawasaki | 92070-0001 |
| N/A | CR8EB |
| NGK | 7784 |
| Peugeot | 769618 |
| Piaggio | 638853 |
| Suzuki | 09482-00570 |
NGK SPARK PLUGS CR8EB Fits Vehicles
- Sea-Doo SPARK TRIXX for 3 (2024)
- Sea-Doo SPARK TRIXX for 1 (2024)
- Sea-Doo SPARK for 3 900 ACE-90 (2024)
- Sea-Doo SPARK for 2 900 ACE-90 (2024)
- Sea-Doo SPARK for 2 900 ACE-60 (2024)
- Sea-Doo SPARK 3up 90 (2023)
- Sea-Doo SPARK 2up 90 (2023)
- Can-Am Ryker Rally 900 ACE (2023-2024)
- Can-Am Ryker Sport 900 ACE (2022-2024)
- Arctic Cat Wildcat Trail LTD (2020)
- Can-Am Ryker Rally Edition 900 ACE (2020-2022)
- Sea-Doo GTI 90 (2019-2022)
- Can-Am Ryker Rally Edition (2019)
- Can-Am Ryker 600 ACE (2019-2024)
- Can-Am Ryker 900 ACE (2019-2024)
- Can-Am Maverick X3 900 HO (2018)
- Arctic Cat Norseman 3000 ES (2019)
- Textron Wildcat Trail (2018)
- Textron Wildcat Sport XT (2018)
- Textron Wildcat Trail LTD (2018)
- Textron Wildcat Trail XT (2018)
- Textron Wildcat Sport LTD (2018)
- Sea-Doo SPARK TRIXX 3up (2018-2023)
- Sea-Doo SPARK TRIXX 2up (2018-2023)
- Arctic Cat Norseman 3000 (2018)
- Arctic Cat Wildcat Sport SE (2017)
- Arctic Cat ZR 3000 (2018-2019)
- Piaggio Fly 150 (2016)
- Sea-Doo GTI SE (2017-2018)
- Sea-Doo GTS (2017-2018)
- Sea-Doo GTI (2017-2018)
- Sea-Doo SPARK TRIXX (2017)
- Arctic Cat Bearcat 3000 LT (2017)
- Arctic Cat ZR 3000 LXR (2017)
- Arctic Cat Wildcat Trail SE (2016-2017)
- Vespa Sprint 150 (2015-2017)
- Arctic Cat Pantera 3000 (2016-2019)
- Arctic Cat Wildcat Trail Limited (2015-2017)
- Arctic Cat Wildcat Sport Limited (2015-2017)
- Arctic Cat Wildcat Sport XT (2015-2017)
- Arctic Cat Wildcat Sport (2015-2016)
- Arctic Cat Wildcat Trail (2014-2017)
- Arctic Cat Wildcat Trail XT (2014-2017, 2020)
- Vespa 946 (2013-2014)
- Sea-Doo Spark 3up 900 H.O. ACE (2014-2022)
- Sea-Doo Spark 2up 900 ACE (2014-2022)
- Sea-Doo Spark 2up 900 H.O. ACE (2014-2022)
- Vespa GT 200 Granturismo (2004-2007)
- Aprilia Sportcity 50 (2009-2010)
- Aprilia Sportcity 250 (2007-2009)
- Aprilia Scarabeo 50 4T (2006-2007)
- Aprilia Scarabeo 250 (2006)
- Aprilia Scarabeo 200 (2008, 2010-2011)
- Aprilia Scarabeo 125 (2003-2006)
- Husqvarna SMS 630 (2011)
- Husqvarna TE630 (2010-2011)
- Husqvarna SM 630 (2010-2011)
- Vespa S 150 (2009)
- Vespa GTV 250 (2009)
- Vespa GTS 250 (2009)
- Vespa LXV 150 (2009)
- Vespa GTS 300 Super (2009)
- Vespa LX 150 (2009)
- Husqvarna SMR 450 (2009-2010)
- Husqvarna TXC 450 (2009-2010)
- Husqvarna TE310 (2009-2011)
- Husqvarna TXC 510 (2009-2010)
- Husqvarna TXC 250 (2009)
- Vespa GT200 (2008)
- Polaris Sportsman 300 (2008-2010)
- Vespa LX 50 (2006, 2008-2009)
- Suzuki LT-R450 QuadRacer (2006-2009)
- Polaris Hawkeye 2x4 (2006-2011)
- Polaris Hawkeye 4x4 (2006-2007)
- Suzuki RMZ250 (2005-2006)
- Husqvarna SMR 510 (2005, 2009)
- Kawasaki KX250F (2004-2006)
- Husqvarna TE510 (2004-2005, 2009-2010)
- Husqvarna TE450 (2004-2005, 2009-2011)
- Husqvarna TC510 (2004-2005, 2009)
- Husqvarna TE250 (2002-2005)
- Husqvarna TC450 (2002-2005, 2009-2011)
- Husqvarna TC250 (2002-2005)
- Vespa ET2 (2001-2005)
- Vespa ET4 (2001-2005)
